Summary of Contents for Phoenix Audio Technologies Condor Expansion Kit
Page 1
The Condor Expansion Kit Connection Guide The Phoenix Audio Technologies Condor Expansion Kit allows integrators to easily implement multiple Condors using the Stingray. Each kit includes 2 Condor units, but customers can add additional Condors – up to four per Stingray and up to a maximum of 60 Condors by daisy chaining a total of 15 Stingrays.
Page 2
Using a CAT5e or CAT6 shielded cable, connect the Remote Audio Extender to the Local Audio Extender. • Connect the included power supply from the Local Audio Extender into a power outlet. Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4774...
Page 3
(GND) port. Make sure to push the ends of the cables, ferrules, securely into the Stingray unit, with no part of the ferrule tip exposed. Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4774...
Page 4
Using the Stingray’s built-in power amplifier, you may now connect up to 4 wired speakers. • The Stingray supports 70-Watt 8 Ohm speakers. Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4774...
Page 5
When the installation is completed, access the Stingray settings either using the front LCD screen on the device or logging into the IP address of the Stingray when connected to the same network. See instructions below. Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4774...
Page 6
From the front panel, enter the menu. Scroll down to the second menu item, “automatic mixer selection.” Press Enter and select “mix line input.” Press Enter again, select the lines the Condors are connected to, and set them to the “mixer” option. Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4774...
Page 7
Stingray GUI After logging into the IP address of the Stingray, select “Device Setup.” Select the primary unit and then “Edit Primary Parameters”. Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4774...
Page 8
Condor units and set each to the “MIXER” option. For setup assistance or any additional technical questions, contact Phoenix Audio Technical Support at (818) 937-4779 or email us at support@phnxaudio.com. Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4774...
