Using the Sennheiser Ceiling Mic with the Phoenix Stingray.
nnheiser Ceiling Microphone is powered by an external power supply and produces a line level
Therefore it should be connected to one of the Stingray's Line Level input. Consequently, the Sting
ixer should be assigned to the Line inputs. The default levels of the SL microphone are adequate
Stingray, and the Line Inputs of the Stingray have a fixed gain structure. That means that no setting
to be done and the two product would work together fine out of the box.
cting the SL Mic:
Mic has three connectors at its back – POWER, CONTROL, and AUDIO OUT.
nect the supplied POWER cable to the microphone (4-Pin Black Connector).
nect the supplied CONTROL Cable to the microphone (6-Pin Black Connector).
en using with the Stingray, this cable is not used (Green Connector). The cable is required to be
nected to the microphone in order to turn on.
eck Sennheiser's Instructions on "How to Use Third Party Mixers" for additional details.
nected the supplied AUDIO cable to the microphone (3-Pin Black Connector).
ove grey 3-position connector from supplied AUDIO cable with screwdriver.
Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4779
Using the Sennheiser Ceiling Mic with the Phoenix Stingray.
Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4779
Advertisement
Related Manuals for Phoenix Audio Technologies Condor
Summary of Contents for Phoenix Audio Technologies Condor
- Page 1 AUDIO cable to the microphone (3-Pin Black Connector). ove grey 3-position connector from supplied AUDIO cable with screwdriver. Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4779 Using the Sennheiser Ceiling Mic with the Phoenix Stingray.
- Page 2 2) Condor Microphone Array 3) Soundbar The Condor Microphone Array (MT600) is only a microphone solution and it is rec- ommended to use external speakers, like a soundbar. The Condor has both optical and RCA outputs to be used with majority of the speaker solutions available on the market.
- Page 3 Step 2: Connect Condor (MT600) to PC/Mac computer. Plug in Condor (MT600) and power on device, speakers, TV, and computer. Upon start-up, the Condor (MT600) will initialize and make a few audio notifications used measure and diagnose any audio issues which the digital signal processor will auto- matically correct the issues.
- Page 4 *Note - ‘Software Echo Cancellation” and “Automatically Adjust Micophone Level” feature will conflict with the hardware DSP and cause poor performance. Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4779 Using the Sennheiser Ceiling Mic with the Phoenix Stingray.
- Page 5 -Check to ensure both the “Test Microphone” and “Test Speaker” selection is (PHNX MT600) -Disable “Automatically Adjust Microphone” -Enable “Preserve original sound from microphone” Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4779 Using the Sennheiser Ceiling Mic with the Phoenix Stingray.
- Page 6 Zoom Quick Setup Video for Condor: https:/ /www.youtube.com/watch?v=UNmOGfq9znw For additional support please visit: https:/ /www.phnxaudio.com/zoom/ https:/ /www.phnxaudio.com/support/ Phoenix Audio Technology Support: (818) 937-4779 Phoenix Audio Technologies | 16 Goodyear #120, Irvine, CA 92618 | 818-937-4779 Using the Sennheiser Ceiling Mic with the Phoenix Stingray.
