Operating Instructions Manual
Please read and save these instructions. Read through this owner's manual carefully before using product. Protect yourself and others
by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal injury and/or
damage to product or property. Please retain instructions for future reference.
DESCRIPTION
High Pressure Portable Grease Pump for quick effortless greasing in everyday lubrication such as greasing of excavators
& other earth moving equipment, automotive & agricultural equipment etc. Pump operates using the Foot Lever, which
greatly reduces effort & allows high pressure greasing with highest comfort. It can be operated by hand when under low
machinery. It is designed with all moving parts submerged in the same grease which needs to be pumped, thereby staying
lubricated at all times. Moving parts create wave action in grease, auto removing air pockets & eliminating the use of a
Follower plate.
Steel Drum Cover
Steel Bucket
Foot Lever
Nozzle Holder
Rubber Pads
SPECIFICATIONS
Discharge Rate
Mechanism
Delivery Pressure
Bucket Capacity
Delivery Hose
Delivery Nozzle
GET969
Printed in India
01/12
Foot Operated Grease Pump
Lift handle
Up to 0.07 oz. per stroke
Foot Operated
8700 PSI
22 lbs.
2 m Long X 1/4" I.D
Steel Extension with coupler
1
Cover Locks
High Pressure Grease Hose
15F220
Pistol Handle
Steel
Extension
Coupler
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Westward 15F220
Summary of Contents for Westward 15F220
-
Page 1: Specifications
Operating Instructions Manual 15F220 Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. -
Page 2: Warranty
Westward Operating Instructions 15F220 Foot Operated Grease Pump WORKING OF PUMP OPERATION & USE The pump has a spring loaded wave action mechanism 1. Fill correct grade grease into the pump bucket. installed at the bottom of the bucket. 2. Tamp the bucket on a firm surface to push the... -
Page 3: Especificaciones
Instrucciones de servicio 15F220 Por favor lea y guarde estas instrucciones. Leer a través de este manual de instrucciones antes de usar el producto. Protéjase a sí mismo ya los demás observando toda la información de seguridad, advertencias y precauciones. El incumplimiento de las instrucciones podría resultar en lesiones personales y / o daños al producto oa la propiedad. -
Page 4: Operación Y Uso
Westward Operating Instructions 15F220 Bomba Accionado de Grasa Por el Pie TRABAJO DE LA BOMBA OPERACIÓN Y USO La bomba tiene un mecanismo de muelle acción de las 1. Rellene grasa de grado correcta en el cubo de la olas instalado en la parte inferior de la cubeta bomba. -
Page 5: Spécifications
Instructions de d’exploitation manuel 15F220 S’il vous plaît lire et conserver ces instructions. Lisez ce manuel attentivement avant d’utiliser ce produit. Protégez-vous et les autres en observant toutes les informations de sécurité, les avertissements et mises en garde. Défaut de se conformer à ces instructions peut entraîner des blessures et / ou des dommages au produit ou les biens. -
Page 6: Fonctionnement Et Utilisation
Westward Operating Instructions 15F220 Pompe de Graisse a Pied TRAVAIL DE LA POMPE FONCTIONNEMENT ET UTILISATION La pompe a un mécanisme à ressort chargé action des 1. Remplissez correctement la graisse de grade dans le vagues installé au fond du godet.
