Euro-Caliper IV
54-100-330-1
Internal Jaws
Step
Measuring
Face
External Jaws
Functions
Locking Screw
Display
Battery Cover
Function Buttons
Battery Replacement
Thumbroll
Beam
In case of water / coolant splash:
The electronic unit for this instrument is water
resistant. In case of liquid splash, the display
may possibly fail. Wipe off the liquid, be sure the
liquid between the slider and beam is completely
dried. Then reset the instrument.
IMPORTANT!
Initial Operation
This electronic caliper comes supplied with a
battery and is instantly operational. However,
we suggest you read this manual prior to using
your instrument.
Depth Measurement Rod
Cleaning
Advertisement
Table of Contents
Related Manuals for Fowler Euro-Caliper IV
Summary of Contents for Fowler Euro-Caliper IV
- Page 1 Euro-Caliper IV IMPORTANT! 54-100-330-1 Initial Operation This electronic caliper comes supplied with a battery and is instantly operational. However, Locking Screw Internal Jaws we suggest you read this manual prior to using Display your instrument. Depth Measurement Rod Step Thumbroll...
- Page 2 Troubleshooting Chart Symptom Corrective Action • Digits do not change or count • Remove the battery for 30 seconds correctly then reinstall. • No Display • Check battery contacts or replace battery. RESET: In order to RESET the instrument, remove the battery, wait 30 seconds, replace the battery and turn the instrument on.
