Overview
This quick installation guide describes the objectives, organization
and basic installation of the PLANET DVR-460/DVR-860 surveillance
system, and offers stand-alone system to build a distributed
surveillance system, which can be monitored over the Internet, and
equipped with Hard Disc Drive that records the video directly. Also,
this guide shows you how to find additional information on related
products and services.
Package Content
DVR-460 / DVR-860
Power Adapter
User's Manual CD
Quick Installation Guide
Screws
DSUB PIN Connector
IR Receiver
Remote Controller
Flat Cable Clamp
If any of the above items are missing or damaged,
NOTE:
contact your local dealer for support.
Advertisement
Table of Contents
Related Manuals for Planet DRV-460
Summary of Contents for Planet DRV-460
-
Page 1: Package Content
Overview This quick installation guide describes the objectives, organization and basic installation of the PLANET DVR-460/DVR-860 surveillance system, and offers stand-alone system to build a distributed surveillance system, which can be monitored over the Internet, and equipped with Hard Disc Drive that records the video directly. Also, this guide shows you how to find additional information on related products and services. -
Page 2: Installing Hdd
DVR-460 Installation Installing HDD 1. Loosen the screws on the upper cover and open the upper cover of the DVR. 2. Screw out the HDD bracket. For the positions of the HDD bracket screws, please refer to the figure below. 3. When install the first HDD, please set the jumper on the HDD to “Master”... -
Page 3: Hardware Installation
5. Connect the HDD to the power connector and IDE BUS (make sure to align the HDD precisely for pin connection) (Refer to Fig. 6. Close the upper cover of the DVR and fasten all the screws you loosened in the step 1. (Refer to Fig. 4 & 5) ONLY use the power adapter supplied with DVR- NOTE: 460. - Page 4 DVR-860 Installation Installing HDD 1. Loosen the screws and open the upper cover. 2. When install the first HDD, please set the jumper on the HDD to “Master” mode.
- Page 5 3. Screw out the HDD bracket from DVR. (Step 1~2) 4. Screw HDD onto the HDD bracket, there is two screws for each side. And then screw the HDD bracket back to the DVR base. (Step 3 ~ 8) 5. Connect the power connector and IDE BUS of DVR to installed HDD.
-
Page 6: Further Configuration
If you want to configure DVR-460/DVR860 and know the further operation, please refer to our manual in the CD disk. If you have any difficulty on resolving the problem while installing or using DVR-460/ DVR-860, please feel free to contact PLANET for support. - Page 7 This page is intentionally left blank...
- Page 8 This page is intentionally left blank...
- Page 9 Part NO: 2011-AB3740-000...
