- Page 1 W i r e l e s s R e v o l u t i o n http://www.wirevo.com Printed in Korea...
- Page 2 Blue flash per 6 seconds Blue flash per 6 seconds Please refer to User Manual for more detail instructions. You can also visit http://www.wirevo.com For e-mail support: support@wirevo.com For USA customers, support.usa@wirevo.com...
-
Page 6: Table Of Contents
Table of Contents Introduction Guidelines for your safety Before Using 1. What’s in the box? 2. Features at a glance 3. Usage cases 4. Charging 5. Turning the dongle ON/OFF 6. Indicator Light Pairing/Connecting 1. Paring & Connecting the dongle with a Bluetooth headset 2. -
Page 7: Introduction
Dongle series will turn your old-fashioned audio players to state-of-the-art ones. The Bluetooth stereo function can be enabled by just plugging wiREVO D1000V into the audio jack of your audio players- MP3 player, CD player, Walkman, Computer, PDA, TV, Audio system etc.-. -
Page 8: Guidelines For Your Safety
Guidelines for your safety Before use, read the warnings and other information in this manual. Please check for any information on RF exposure in usage of a dongle. When your dongle is turned on, it transmits and receives radio frequency electromagnetic fields in the frequency range 2.402 ~ 2.480 GHz. -
Page 9: Before Using
Before Using 1. What’s in the box? wiREVO D1000V USB cable User manual The contents are subject to change without notice and may vary from image shown. 2. Features at a glance Volume Up button Volume Down button Microphone Jack... -
Page 10: Charging
4. Charging Before using the dongle for the first time, make sure the dongle is fully charged. Connect the USB cable to the dongle and the indicator light will be purple. [Charging] When the battery is fully charged, the blue indicator light will turn on if power is off, or the indicator light will display normal operation if power is on. -
Page 11: Turning The Dongle On/Off
5. Turning the dongle ON/OFF To turn on the dongle, push the ON/OFF Switch ( ) to the direction for ‘ON’. To turn off the dongle, push the ON/OFF Switch ( ) to the direction for ‘OFF’. 6. Indicator Light Indicator light status Power On as Analog audio + Internet chatting mode or as Blue &... -
Page 12: Pairing/Connecting
Pairing/Connecting 1. Paring & Connecting the dongle with a Bluetooth headset You need to pair the dongle with the Bluetooth headset that you intend to use it with. This process is to set-up a unique wireless link between two devices. Once you have paired your dongle with the Bluetooth headset, you don’t need to pair it again. -
Page 13: Connecting To The Latest Connected Bluetooth Headset
2. Connecting to the latest connected Bluetooth headset 1. Switch ON ( ) and the dongle will try to connect to the latest connected Bluetooth headset and the blue indicator light will flash per 1 second. [Connecting mode] 2. When connecting has been completed successfully, the blue indicator light will flash per 6 seconds. 3. -
Page 14: Using The Dongle
Using the dongle Mode Setting Power ON Menu button Volume Down button Volume Up button Summary Pairing Mode ON+Menu Analog audio +Internet chatting mode ON+Vol(-)+Vol(+) Analog audio mode ON+Vol(-) USB audio mode ON+Vol(-)+Menu To listen to music, you should use a Bluetooth stereo headset with the dongle. Just for using the wireless internet chatting, you can use a Bluetooth mono headset. - Page 15 2. Make/Answer call [Making a call] Input the phone number in the internet chatting program of your computer and click the call button. Press Talk button of the headset. The purple indicator light will flash every 3 seconds. [Talking status] [Ending a call] Click the end button of the internet chatting program.
- Page 16 MSN Messenger call Making a call Initiate a call. - In the main Windows Live Messenger window, click ‘Actions’, point to ‘Call’, and then click one of the following: - Call a contact's computer. Select the contact you want to call or type an e-mail address in the box at the bottom of the window, and then click ‘OK’...
-
Page 17: Analog Audio Mode
3. Play Music Check the dongle is Audio status, not Talking status. [Play/Pause music] Press Play/Pause/Stop button of the stereo headset or press Menu ( ) button of the dongle. In this mode, if you have the music paused by operating as above, it makes the dongle paused, does not make the device, that the dongle is plugged into, paused. -
Page 18: Usb Audio Mode
When you plug the dongle into the USB port of a non-Bluetooth device for the first time, it will install USB Audio Device Drivers automatically and additional USB Driver is not needed. Installed Audio Device’s name is “wiREVO Bluetooth Stereo Audio”. If it is not selected... -
Page 19: Specification & Certifications
These products are CE marked according to the provisions of the R&TTE Directive 1995/05/EC. These products are in compliance with the essential requirements and other relevant provisions of Directive 1995/05/EC. For more information please consult http://www.wirevo.com. These devices comply with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) These devices may not cause harmful interference, and (2) these devices must accept any interference received, including interference that may cause undesired operation. - Page 20 Thank You. To receive sales literature and technical assistance, please contact the following address. support.usa@wirevo.com Address: 2480N, First Street, Suite 100, San Jose, CA 95131-1030, USA Visit our Web site at www.wirevo.com Printed in Korea...
