FIBARO FGBHPB-101-S Manual

ENGLISH
FIBARO Button is a HomeKit-enabled, compact,
battery-powered remote using Bluetooth
energy technology. It allows you to control HomeKit
accessories using Automations.
Different actions may be triggered with one click,
two clicks or by holding the button down.
TIP: Check corresponding chapters of Quick Start
Guide for pictures.
Package contents (page 3):
• Device,
• Manuals and warranty terms,
• Mounting parts,
• Sticker.
Download FIBARO app from the App Store (page 4).
First launch (page 5):
1) Press and turn the button counter-clockwise to
open the casing (Fig. 1).
2) Remove the battery blocker and check if the bat-
tery is placed correctly (Fig. 2).
3) Press and turn the button clockwise to close the
casing (Fig. 3).
4) Open the FIBARO app and tap
5) Application will guide you through the pairing
process.
6) Install the device in desired location using the at-
tached self-adhesive pad (Fig. 5 & Fig. 6).
Setup Code:
You will find the Setup Code on the back of the
Quick Start Guide. Remember to keep it in a safe
place. You may need it in case of re-pairing.
Reset (page 7):
1) Click the button exactly five times (Fig. 7).
2) Press and hold the button for at least 5 seconds.
3) Long beep will confirm resetting.
®
low
manuals.fibaro.com/en/hk-button
Specifications:
Power supply:
Radio protocol:
Radio frequency:
Operating temperature:
Dimensions (d x h):
EU directives compliance:
Warnings:
Failure to observe recommendations included in the manual
may cause risk to health or malfunction of the device. The
manufacturer, Fibar Group S.A. will not be held responsible for
any loss or damage resulting from not following instructions
of the manuals.
Using batteries other than specified may result in explosion.
Dispose of properly, observing environmental protection rules.
Legal information:
icon (Fig. 4).
Fibaro and Fibar Group are registered trademarks of
Fibar Group S.A. The Bluetooth word mark is registered trade-
mark of Bluetooth SIG, Inc. Apple and HomeKit are registered
trademarks of Apple Inc.
Use of the Works with Apple HomeKit logo means that an elec-
tronic accessory has been designed to connect specifically to
iPod touch, iPhone, or iPad, respectively, and has been certified
by the developer to meet Apple performance standards. Apple
is not responsible for the operation of this device or its compli-
ance with safety and regulatory standards.
Hereby, Fibar Group S.A. declares that FIBARO Button is in
compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
For more information about
FIBARO Button, like
guides, technical manuals, and
declarations visit our website:
ER14250 (½AA) 3.6V battery
®
Bluetooth
0-40°C (32-104°F)
46 x 34 mm (1.81" x 1.34")
R&TTE 1999/5/EC
RoHS 2011/65/EU
video
low energy
2.4 GHz
