INSTRUCTIONS
WARNING: READ INSTRUCTIONS BEFORE OPERATING
1. Center load on table - 1000 lb. maximum.
2. Connect to 100 psi maximum shop air.
3. Keep safety bar in position at all times - except
when lowering.
4. Keep hands and tools from under carriage.
5. Do not mount table when in elevated position.
6. Do not ride vehicle onto lift.
7. Lift must be in the lowered position when moving.
8. Only trained persons should operate Air Lift.
9. The working area should be sufficiently lit.
10. Foot controller should be at least 3 feet away from
Air Lift during raising and lowering operation.
11. Recommended for indoor use only.
HANDY INDUSTRIES DIVISION OF JADEIM, LLC
1-800-247-7594
AIR LIFT
PARTS DRAWING
l
Part Numbers 10740 - 16749 - 16600
LIFT TABLE
Fax 641-752-1205 www.handyindustries.com
PARTS LIST
l
RAMP
DETENT BAR
SAFETY LATCH
FOOT VALVE
401 South 2nd.
Marshalltown, IA 50158
Advertisement
Related Manuals for Jadeim Handy 10740
Summary of Contents for Jadeim Handy 10740
- Page 1 9. The working area should be sufficiently lit. 10. Foot controller should be at least 3 feet away from Air Lift during raising and lowering operation. 11. Recommended for indoor use only. HANDY INDUSTRIES DIVISION OF JADEIM, LLC 401 South 2nd. Marshalltown, IA 50158 1-800-247-7594...
- Page 2 AIR LIFT NOTE: READ ENTIRE MANUAL TO COMPLY WITH ALL SAFETY AND SERVICE PRECAUTIONS. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY. INSTRUCTIONS UNPACKING AND SET-UP 1. Open carton, then remove ramp, and shipping boards. 2.
- Page 3 REPLACEMENT PARTS PART NO. DESCRIPTION QTY/UNIT PART NO. DESCRIPTION QTY/UNIT 10819 Detent Clip 11250 Screw ¾-10 x 1¾ 11008 Frame/Cylinder Pivot Shaft 11251 ½ -13 Hex Nut 11052 Top Assembly 11252 Cam Bearing Retaining Ring 11167 Cylinder Assy & End Plate (Gray) 11253 Wheel Retaining Ring 11071...
- Page 4 HANDY LIMITED WARRANTY Handy Industries Division of Jadeim LLC, warrants to the original purchaser of this product, all parts to be free from defects in manu- facture for a period of one (1) year from date of delivery. Notice of a defective part must be received in writing at Handy Industries with- in one (1) year of purchase.
