Installing; Cleaning; Technical Data - Becker Centronic VarioControl VC581 Assembly And Operating Instructions Manual

Plug the VC581 into a power socket. When choosing a plug socket, make sure
that the VC581 will optimally extend your radio network by locating it approxi-
mately half way between the radio transmitter and receiver for which you wish
to extend the radio range.
The VC581 works best if placed at a higher level, e.g., on a shelf or on top of a
cupboard. Make sure that there are no metal surfaces in close proximity to the
radio repeater such as a steel cabinet or a metal window sill, as these can seri-
ously impair the function of the radio repeater.
When positioning the VC581, we recommend using a radio analysis tool to check
that the radio signal is stronger at the receiver to which it is coupled.
Clean the device with a damp cloth only. Do not use a cleansing agent since this
could damage the plastic.
Nominal voltage
Protection class
Permissible surrounding temperature
Radio frequency

Installing

Cleaning

Technical data

230 V / 50 Hz
IP 20
0 to +55 °C
868.3 MHz
de
en
fr
nl
13
