- Page 1 CONVERGE PA 460 ® Professional Power Audio Amplifier Quick-Start Guide...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ................3 SAFETY INFORMATION ..............3 UNPACKING .................. 4 FRONT PANEL ................5 BACK PANEL ................. 6 MOUNTING ..................9 COMPLIANCE ................9 CLEARONE CONTACTS.............. 10... -
Page 3: Introduction
INTRODUCTION QUICK-START GUIDE CONVERGE PA 460 amplifier is a 4 Channel x 60 Watts, high-efficiency Class-D power audio amplifier for reliable amplification with professional sound quality for conferencing, sound reinforcement, and distribution applications. The amplifier is optimized to work with ClearOne’s DSP mixers, and it also works with any third-party mixers. -
Page 4: Unpacking
CONVERGE PA 460 AMPLIFIER AVIS: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR UNPACKING Use the illustrations below to verify that you have received the following components. Inspect your shipment carefully. If the shipment shows obvious signs of damage, retain original boxes and packing material for inspection by the carrier, and contact them immediately. -
Page 5: Front Panel
FRONT PANEL QUICK-START GUIDE Clip LED Indicator Power LED Indicator Signal LED Indicator Standby LED Indicator Limit LED Indicator Protect LED Indicator 1. CLIP A red light indicates when the input is at ~0dBu and signal clip is on. There are Clip indicators for each of the four channels. 2. -
Page 6: Back Panel
CONVERGE PA 460 AMPLIFIER 6. POWER A blue power indicator light turns on when the unit is powered. Per Pair of LED ON Function Indicator Details Channel Channels Color Indicator Indicator Clip Signal clip, peak detected Signal Blue Audio signal present... - Page 7 QUICK-START GUIDE 3. SPEAKER OUTPUTS Four Phoenix Euroblock speaker output channels can be connected to either high-voltage speakers (70V/100V) or 4/8Ω line speakers, depending on which wires you connect. WARNING: Never connect the negative terminal to the positive terminal. Doing so can trigger the short circuit protection. WARNING: Do not mix 4/8Ω...
-
Page 8: Gain Control
CONVERGE PA 460 AMPLIFIER CH 1 In CH 2 In Bridge 100V CH 1 Out CH 2 Out 1&2 4- 8 Ω / 4- 8 Ω / 4- 8 Ω / 120W 70V / 120W 100V / 120W Bridge CH 3 Out CH 4 Out CH 3 In... -
Page 9: Mounting
QUICK-START GUIDE Potentiometer Max Input Output power with 0 dBU input Output power with 0 dBU input Position (60W output mode) (120W output mode) 0 dBu 120W +1 dBu +5 dBu +8 dBu +12 dBu +16 dBu +18 dBu +21 dBu 550mW 1.1W +26 dBu 218mW 436mW +35 dBu 27mW 54mW mute mute mute MOUNTING Mount up to two units in a 1 RU rack mounting kit. -
Page 10: Compliance
CONVERGE PA 460 910-3200-401 Mounting Kit for CONVERGE PA 460 910-3200-402 930-3200-401-1 Bundle: Qty 1 CONVERGE PA 460 Amplifier unit with Qty 1 Rack Mounting Kit Bundle: Qty 2 CONVERGE PA 460 Amplifier units with Qty 1 Rack Mounting 930-3200-401-2 COMPLIANCE Details on compliance can be found on the ClearOne website under “Resource...
