Chamberlain 90-5024 Installation Instructions

APPLICATION REQUIREMENTS:

This wiring modification is available for Door and Gate operators with 24VAC control circuits (See list below for
operator list). Not available with Hazardous Area or Variable Speed modifications. Not necessary on operators
with Logic Control Boards.
Door Operators: T, GT, J, H, GH, SD and GSD
●
Gate Operators: SL540, SL570, SL580, SL590, SW420, SW470 and SW490
●

FUNCTIONS:

1) Control stations are to be located more than 100 ft. from the operator (allows up to 1000 ft. of control wiring
between controls and operator with 16GA. wire).
2) Control stations are to be electrically isolated from the operator.

PREPARATION:

Unpack kit to verify the parts listed below are included.
PART NUMBER
002B0422 LONG DISTANCE MODULE
40-12407 LABEL, 4 POLE TERMINAL BLOCK (1A, 2A, 3A, 4A)
42-104 TERM BLOCK, 4 POSITION
80-362-1 WIRE NUT, BLUE
80-362-2 WIRE NUT, ORANGE 600V
82-PX08-10T SCREW, PAN HEAD #8-32 X 5/8" LONG, SELF TAPPING
84-FN-08 SERRATED FLANGE NUT, #8
92-SJ-3526 VELCRO, 1" WIDE
92-SJ-3527 VELCRO, 1" WIDE
WARNING
DISCONNECT POWER AT THE FUSE BOX
BEFORE PROCEEDING. OPERATOR MUST
BE PROPERLY
PERMANENTLY WIRED IN ACCORDANCE
WITH LOCAL ELECTRICAL CODES. ALL
ELECTRICAL CONNECTIONS MUST BE MADE
BY A QUALIFIED INDIVIDUAL.
WARNING
ANY MAINTENANCE TO THE OPERATOR OR
IN THE AREA NEAR THE OPERATOR MUST
NOT BE PERFORMED UNTIL DISCONNECTING
THE ELECTRICAL
COMPLETION OF MAINTENANCE THE AREA
MUST BE CLEARED AND SECURED, AT THAT
TIME THE UNIT MAY BE RETURNED TO
SERVICE.
WARNING: This product can expose you to chemicals
including lead, which are known to the State of California to
cause cancer or birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
DESCRIPTION

IMPORTANT SAFETY NOTES

GROUNDED AND
POWER. UPON
(DC) Long Distance Control Wiring
INSTALL THE CONTROL STATION WHERE THE
DOOR IS VISIBLE, BUT AWAY FROM THE
DOOR AND ITS HARDWARE. DO NOT INSTALL
CONTROL STATION DIRECTLY BENEATH THE
OPERATOR. IF CONTROL STATION CANNOT
BE INSTALLED WHERE DOOR IS VISIBLE, OR
IF ANY DEVICE OTHER THAN THE CONTROL
STATION IS USED TO ACTIVATE THE DOOR, A
SAFETY DEVICE MUST BE INSTALLED ON
THE DOOR, THE MINIMUM ACCEPTABLE
DEVICE WOULD BE SAFETY PHOTO EYES,
OR A REVERSING EDGE INSTALLED ON THE
BOTTOM OF THE
PROTECTION IS
COMBINATION OF THESE TWO DEVICES.
WARNING
THIS UNIT MUST BE PROPERLY GROUNDED.
A GROUND SCREW IS SUPPLIED IN THE
ELECTRICAL BOX FOR CONNECTION OF THE
POWER SUPPLY GROUND WIRE. FAILURE TO
PROPERLY GROUND THIS UNIT COULD
RESULT IN ELECTRIC SHOCK AND SERIOUS
INJURY.
24VAC Control Circuit
90-5024
QUANTITY
1
1
1
4
4
2
2
1"
1"
WARNING
DOOR. THE BEST
AFFORDED BY THE
