- Page 1 Catalogue www.pegasustech.net Product Characteristic and Function and Use Description Setting Operation........Multiple Languages and Checking Data Upload Speed Settings......Barcode Type Settings Barcode Enable Settings Add Prefix and Suffix Settings...
- Page 2 Respected clients： Thanks for choosing us. We hope you take your valuable time to read the user manual before using the barcode reader. Hope this will be a good base for a smooth use. Any enquiries, please contact us. Thanks. I Product Characteristic: a.Exquisite and beautiful design, external protected by soft rubber and internal scientific solidification structure, so its drop resistance better than ordinary scanner.
- Page 3 Function and Use Description a. Automatic frequency hopping and strong anti-interference capacity. b. Under the “Normal Mode”, the transmission distance is 20m-100m where there are obstacles, the transmission distance is over 400m where there are no obstacles. If exceed the transmission distance or the data is loaded failed,3 short prompt sound will be sent out. c.
- Page 4 Pairing and ID Setting Operation 2 ) I D D is p la y a nd Hi d in g S et t in g s 1 )Pai rin g an d ID S e t t i n g s Openi ng Pa ir i ng ID Display O p e n i n g I D S e t t i n g...
- Page 5 3)Sleeping Time Settings Opening Time Setting 2min 5min 10min 8hour 20min 4) Working Mode Setting No Sleeping Non-Losing Mode Common Mode Checking Mode Clear Data Total Data Data Upload...
- Page 6 Multiple Languages Settings German English Italian Franch Czech Turkish Spanish Finnish Checking Data Upload Speed Setting Serial Port Baud Rate Setting (Note: This setting is suitable for serial receiver only.) 115200 38 40 0 1 9 2 0 0 9600...
-
Page 7: Auto Scanning Mode
Barcode Restore Factory Settings Restore Factory Settings Quit Settings Enter Into Settings Attention: Before any function settings , please read "Enter Into Settings"-read the needed function settings-"Quit Settings ".If there is any unwanted function earlier, please read "Restore Factory Settings" to restore the factory settings. Flicker Scanning Mode Flicker Scanning Flicker Scanning Time... -
Page 8: Continuous Scanning Mode
Enter Into Settings Quit Settings Attention：Press the switch button after Auto Scanning Mode setting is accomplished, the scanner will automatically read the following barcodes.If re-press the switch button,the scanner will stop reading barcodes. By default, it is not allowed to read the same barcodes. Under the auto scanning mode, the reading barcode time can be set and time unit as 1s, the parameters range is 0-15s, 0 is infinite and can set if allowed to repeat reading the same barcode. - Page 9 Attention：When Continuous Scanning Mode set,the scanner enters into continuous reading code without pressing switch button.Under continuous scanning mode, the scanner can set the scanning interval time and the interval time unit as 500ms, parameter range is 0-7500 ms. Under continuous scanning mode allows continuously read the same barcode via setting scanning interval time. Read the same barcode twice in 0.1 seconds, the time interval can be set between 0 and 12.0 seconds.When set to 12.7 seconds means not allow to read the same barcode.The numerical must have three numbers, zero shows if less than three numbers.
-
Page 10: Barcode Type
Attention: The code ID before the barcode means the corresponding barcode type, please check the sheet1-1. (Sheet 1-1) Barcode Type Barcode Type CODE ID CODE ID ITF-6 UPC-A ITF-14 UPC-E Matrix 2 of 5（Europe） EAN-8 Matrix 2 of 5（Japan） EAN-13 Industrial 25 ISSN ISBN... - Page 11 Enter into Settings Quit Settings Barcode Character Transfer Delaying Settings Attention: character delaying time is 0-75ms, 5ms as a grade, 15 grades in total. The default is 0ms. Character Delaying Time Barcode Enable Settings Read All Types of Barcode Forbid to Read All Type of Barcode Attention: if some barcode can't be read’...
- Page 12 Enter into Settings Quit Settings UPC/EAN- Attached Code settings Adding Two Bit Attached Code Adding Five Bit Attached Code Code39 to or not to transmit start character and stop character to Transmit Not to Transmit Cancel Enetr and Enter Setting Enter Cancel Enter...
- Page 13 Enter into Settings Quit Settings Add Prefix Settings Add Prefix Not Reveal Prefix Reveal Prefix For example: If add prefix “XY” before code “1234”, steps as follows： 1. Enter into Settings 2. Add Prefix 3. Read parameter code 5,8,5,9 and then read “Save” 4. Quit Settings. After above settings and read “Reveal Prefix”...
- Page 14 Parameter Code PS： If it reads the parameter error, please read the "reset parameter" code to reset the needed parameter Save Reset Parameter...
- Page 15 Parameter barcode and corresponding representing characters table. Parameter Parameter Parameter Parameter Parameter Representing Representing Representing Representing Representing characters characters characters characters characters code code code code code ASCII Code Setting (PS:This setting aims to code 39 reading incompleted characters.) Close Open...
- Page 16 Add the Function Key Terminator Quit Settings Enter into Settings Add Terminator HOME...
- Page 17 IV Simple Operation Guide I)Pairing Operation: Insert the receiver into the computer USB interface, the receiver emits blue lights. Turn on the scanner, scanning “Opening Pairing Setting”, then scanning number you need(Read “0” and “1” represent the channel is 1), this time, the blue light twinkles. This shows the scanner can communicate.
- Page 18 III）Switching Off When the scanner arrives at the previous set sleeping time, it is switched off automatically (the default setting is 20s ). Meantime it can be switched off compulsively by pressing the on/off button for 2 seconds. if the sleeping time is too short, an self-customize sleeping time(e.g.2minutes) IV) Charging Please use our equipped charging cable to charge the scanner.
- Page 19 V Sound Promotion Guide I) Scanning setting alarm: One short beep. II) Pairing operation failure: Six short beeps. III) Data Uploading Success: one short beeps, Failure: three short beeps. IV) Low voltage alarm: A long beep happens when the scanner is on or scanning. V)Charging interface type: RJ-45 crystal head, one meter long (equipped with 5V charger;...
-
Page 20: About The Warranty
About the Warranty I.Since you buy our product with this card, you can enjoy the service of one year repair and lifelong maintenance for the rubber and plastic parts of the barcode scanner,6 months repair service for the battery and the charger, and 3 months repair service for the data cable. - Page 21 Name Name Address Address Zipcode Zipcode Operator Signature Email Distributor Seal...
-
Page 22: Barcode Reader
Maintenance Record List Warranty Card Barcode Reader Fault Maintenance Operator Date Description Record Part No. Serial No. Purchase Date Appendix Accessories Name Quantity Scanner U Type Receiver USB Charge Cable Manual Please make sure to read the instructions about maintenance carefully at the back of the card, fill out various data above carefully and the file is valid only if it is signed with the official seal of the authorized dealer.
