- Page 1 User’s Manual Portable Beveling Machine #312, Migun Techno World 2, 187 Techno 2-Ro, Yuseong-Gu, Daejeon, 34025, S.Korea Tel : +82-10-5380-5270 / Web : www.ahaind.com E-mail : aha.overseas@gmail.com...
-
Page 2: Table Of Contents
● Specifications ・・・・・・・・・・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・・・・・ ● Safety Cautions ・・・・・・・・・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・・・・・ ● Order and Procedure of Installation to the Pipes (MP0020-26) ・・・・・・ ・・・・・・ ・・・・・・ ・・・・・・ ● How to Change U-Plate for 6” ~ 8” ・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・... -
Page 3: Specifications
7. Connect the electric source in accordance with local electricity regulations. 8. When you install Chamfer-Mill 2100-00 to Pipe Attachment (MP1020-AD), the level of chamfering depth should always be set at below zero (0) level. MP0020-26 User’s Manual - 3 - AHA Industrial Co / www.ahaind.com... - Page 4 14. Safety cautions should be kept at all times during daily works. When needed, the employer should be responsible for controlling all the work procedures. MP0020-26 User’s Manual - 4 - AHA Industrial Co / www.ahaind.com...
-
Page 5: Order And Procedure Of Installation To The Pipes (Mp0020-26)
Order and Procedure of Installation to the Pipes (MP0020-26) 1. After installation of the Manual Pipe Beveling Machine, confirm whether minimum pipe length projected is more than 140mm so that the machine could be rotated along the pipe and the work space is secured as more than 400mm. - Page 6 11. After the beveling work is finished, turn off the switch of the motor and set the beveling value at below zero (0) level for safety and beveling work next time. MP0020-26 User’s Manual - 6 - AHA Industrial Co / www.ahaind.com...
-
Page 7: How To Change U-Plate For 6" ~ 8
Roller Handle (List No. 5) and Outer Roller Handle (List No. 11) and assemble Hexagonal Adapter (17mmx15) provided instead using Washer (Φ12x1.6t) Outer Roller and Wrench Bolt (M4x8) Shaft provided. MP0020-26 User’s Manual - 7 - AHA Industrial Co / www.ahaind.com... -
Page 8: Differences Of Chamfering Quantity As Per The Installation Method
Application of Plate Beveling and Outside Diameter Beveling of Short Pipes 1. If you purchase MP0020-26 model, all the parts of List No. 28, 29 of Chamfer-Mill are included as standard items and you can do the plate beveling manually too. -
Page 9: Tools And Parts Provided
2 EA 8. Wrench Bolt M5×15 4 EA 9. Hexagonal Adapter .2 EA 10. Wrench Bolt M4×8 2 EA 11. Washer Φ12×1.6t 2 EA 12. O-Ring (NBR P46) 12 EA MP0020-26 User’s Manual - 9 - AHA Industrial Co / www.ahaind.com... -
Page 10: Warranty
4. In case it is proven that the defects are caused by defective materials or poor workmanship of the manufacturing, repair or replacement of defective parts will be provided free of charge by this warranty. MP0020-26 User’s Manual - 10 - AHA Industrial Co / www.ahaind.com... -
Page 11: Mp0020-Ad Parts List / Drawings
MP0020-26 User’s Manual - 11 - AHA Industrial Co / www.ahaind.com... - Page 12 MP0020-26 User’s Manual - 12 - AHA Industrial Co / www.ahaind.com...
