Summary of Contents for logika WL-ZSPCNPW-AL-02
- Page 1 Smart Sound Warner WL-ZSPCNPW-AL-02 Product Manual Version 1.0 © 2019 Logika Limited...
- Page 2 Introduction Thank you for choosing Logika. Please take a moment to carefully read through the manual to ensure safe and proper installation and use. • Before use, the product must be properly installed as described in this manual by a qualified technician.
-
Page 3: Device Layout
Device Layout System Indicator Alarm Speaker Alarm Light Multi-Functional Button Packing List Smart Sound Warner Ceiling-Mounted Base Wall-Mounted Base Screws (x2) + Wall Plugs (x2) Product Manual Warranty Card... -
Page 4: Specifications
Features • Communication Mode: IEEE802.15.4 Zigbee. Can be linked to the other devices, like the Smart Panic Button, and sound an audible alarm. • • Strong anti-interference ability, low false alarm rate. Activate or deactivate defence through local or remote control via the mobile app. •... -
Page 5: Installation Steps
Installation Steps Hardware Installation There are 3 ways that the Smart Sound Warner can be mounted on the ceiling or wall. Each option is described below. Note: The hole for the mains power is 10mm in diameter and the quick connector terminals will accept 14-22 AWG cables. - Page 6 3) Pull the Spring mounts up and push the unit through the hole in the ceiling. Install Option 2 This install option is for mounting without the need for cutting large ceiling holes. For this, you will need the Smart Sound Warner, Wall-Mounted Base, wall plugs and screws (supplied). 1) Place the base onto the ceiling or wall and mark off where to drill.
- Page 7 4) Connect the power cable to the Smart Sound Warner unit and attach to the Wall-Mounted Base attached to the ceiling. Install Option 3 This install option is similar to Install Option 2 but for situations where the cable can only be fed in from the side (i.e.
- Page 8 Adding the Device to the Smart Home Network Use the Logika Smart Home app to add the device to the Smart Home system. Please refer to the Logika Smart Mobile App user guide which will take you through the process of adding smart devices to the system.
-
Page 9: Device Functions
Device Functions When the device is first powered on, it will normally automatically attempt to connect to the Zigbee Smart Home network. The System Indicator light will flash as it’s searching for the network. If it connects, the light will remain on for 2 seconds and then go out. If this does not happen, you can manually connect via the mobile app and follow the instructions below. -
Page 10: User Guide
For instance, you could create a Linkage Task which listens for an alert from your Smart Gas Detector and set this device as a linked device that would sound the alarm once a gas leak has been detected. Refer to the Logika Smart Mobile App user manual to see how you can do this. -
Page 11: Safety Precautions
Safety Precautions • Disable any power prior to connecting the device to the main supply. • The device must be installed by a qualified electrician. • Do not disassemble or refit this product or its accessories. • The device should be mounted in a dry environment. It is not designed to be used outdoors. -
Page 12: Troubleshooting
You should now be free to add the device to the local smart network. The issue you are experiencing is not mentioned here. Please contact us at support@logika.nz with your issue and we will do our utmost to help!
