Sune Technology QVI-LX11(1CH) Series Install Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Your best partner for better driving
SUNE TECHNOLOGY CO.,LTD
No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN
TEL:+88662292246 FAX:+88662288104
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com
SKYPE:sune_tech or hsin_han99
Release Date
2014.03.28
Model
QVI-LX11(1CH)-V7.1 SET
Product Code
LVTX-1CH-1203-005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QVI-LX11(1CH) Series and is the answer not in the manual?

Questions and answers

Related Manuals for Sune Technology QVI-LX11(1CH) Series

Summary of Contents for Sune Technology QVI-LX11(1CH) Series

  • Page 1 Your best partner for better driving SUNE TECHNOLOGY CO.,LTD No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN TEL:+88662292246 FAX:+88662288104 Http://www.sune-tech.com Shop http://www.carnavi-tech.com SKYPE:sune_tech or hsin_han99 Release Date 2014.03.28 Model QVI-LX11(1CH)-V7.1 SET Product Code LVTX-1CH-1203-005...

  • Page 2: Table Of Contents

    Table of Contents 1. Specifications 1.1 Main Specifications 1.2 Features 1.3 System Diagram 1.4 Components 1.5 Exterior 2. Installation 2.1 Installation Diagram 2.2 Use caution 2.3 Installation 3. Settings 3.1 DIP Switch 3.2 Remote Control 3.3 OSD (On Screen Display) 3.4 Factory Mode 3.5 Rear Parking Guidelines 3.6 Touch Calibration...
  • Page 3 Warning / Caution  When installing the main unit, do not remove or alter existing vehicle fasteners, including nuts, bolts, screw, clips, and fittings. Never detach, move or alter existing vehicle wiring, including electrical grounds and straps. Alteration of existing vehicle Warning components may make vehicle unsafe to operate.

  • Page 4: Specifications

    1. Specification 1.1 Main Specifications 1. Main Components Multimedia Interface * 1EA Sub-board * 1EA 2. MULTIMEDIA INTERFACE input specification 3 * A/V (NTST&PAL) Input 1 * CVBS(Rear Camera) Input 1 * Analog RGB 1 * LCD input (Car system input) 3.

  • Page 5: Features

    1. Specifications 1.2 Features  Able to adjust DVD, NAVI on the screen  Improvement in Screen Display(User friendly interface)  Add Safe function (While driving, the screen shows the main page)  A MODE SWITCH button is provided to switch the mode.

  • Page 6: System Diagram

    1. Specification 1.3 System Diagram Switch for source toggle Remote control OEM Navi Button (Can Signal) NAVIGATION Input (Analog RGB) DISPLAY Car Installation A/V 1 OEM LCD VIDEO MUX A/V 2 VIDEO CIRCUIT A/V 3 CVBS (Rear camera) Car Screen Input (CAR MAIN BOARD) POWER A/V OUT...

  • Page 7: Components

    1. Specification 1.4 Components Sub-board Bracket * 1ea (PRESET0155) LVDS cable * 1ea (HLVDSC0020) TOUCH OUT cable * 1ea (HTOUCH0004) Sub-board * 1ea 8P TOUCH cable * 1ea (HTOUCH0017) FFC cable * 2ea (FFCABL0036) 8P FFC cable * 1ea POWER cable (24P) * 1ea (FFCABL0035) A/V cable * 1ea (HPOWER0011)

  • Page 8: Exterior

    1. Specifications 1.5 Exterior ⑥ ⑦ ⑧ Dimension Width 125mm Length 105mm Height 21mm ① LED ② POWER ③ RGB IN-2 ④ R-CAM ⑤ AV(IN/OUT) ⑥ DIP Switch ⑦ TOUCH OUT TO NAVI ① ② ③ ④ ⑤ ⑧ LVDS OUT ⑨...

  • Page 9: Installation Diagram

    2. Installation 2.1 Installation Diagram ※ In case of connecting the LVDS cable cable to Monitor’s module directly, Please use caution especially ESD. It may cause the critical QDIS FFC cable damage on the monitor) QDIS FFC cable TOUCH IN/OUT cable COMMAND Touch cable Navigation...
  • Page 10 2. Installation 2.2 Installation ① Remove the monitor from the vehicle. ② Detach Monitor’s cover from the head unit.
  • Page 11 2. Installation 2.2 Installation ① Separate LCD part from the head unit. ② Disconnect the OEM cables and remove the black plastic connector.
  • Page 12 2. Installation 2.2 Installation ① Attach black connectors to FFC cables provided by us as shown on the left ② Link the new FFC cable to the place where OEM FFC cables were connected. Refer to the right picture. -10-...
  • Page 13 2. Installation 2.2 Installation ① Assemble the bracket provided by us on the top of the body. ② Holes where are marked in red are the place to be assembled with our bracket. -11-...
  • Page 14 2. Installation 2.2 Installation ① take out the FFC cable from the gap of the head unit and then link it to TTL IN of our Sub-board. -12-...
  • Page 15 2. Installation 2.2 Installation ① Remove the cover of LCD part which was separated from the head unit. -13-...
  • Page 16 2. Installation 2.2 Installation ① Connect our touch FFC cable to the place where OEM touch cable was removed. -14-...
  • Page 17 2. Installation 2.2 Installation ① Connect touch out cable to our FFC cable and link touch in cable to OEM FFC cable. -15-...
  • Page 18 2. Installation 2.2 Installation ① Draw out our touch in/out cables and FFC cables between gaps marked -16-...
  • Page 19 2. Installation 2.2 Installation ① TOUCH IN/OUT cables are linked to TOUCH IN/OUT of subboard, FFC cable linked to LCD is connected to TTL_OUT ② Tighten the marked bolts to be fixed with bracket. -17-...

  • Page 20: Settings

    3. Setting 3.1 DIP Switch ※ For example, Use of DIP S/W - Input mode: A/V3, Navigation (RGB) - OEM Navigation Not available - Rear Camera : When it is installed to CVBS4 ▷ DIP S/W : 1  OFF ▷...

  • Page 21: Remote Control

    3. Settings 3.2 Remote Control 기능 POWER & PIP Unavailable MENU Activating OSD menu Making a selection, changing image display ▲ Moving upward ▼ Moving downward Moving leftward ◀ (If you press this button 2 seconds long, you can access the factory mode.) Moving rightward ▶...

  • Page 22: Osd (On Screen Display)

    3. Setting 3.3 OSD (On Screen Display) / Analog RGB Mode  IMAGE  COLOR * BRIGHTNESS * RED * CONTRAST * GREEN * SHARPNESS * BLUE * USER IMAGE * USER COLOR : User settings among four : User settings options ...
  • Page 23 3. Setting 3.3 OSD (On Screen Display) / Video Mode  IMAGE  OSD * BRIGHTNESS * LANGUAGE : Set OSD language * CONTRAST (only support English and Chinese) * SATURATION * TRANS : Adjust OSD transparency * HUE * H-POSITION : Move OSD horizontally * SHARPNESS * V-POSITION : Move OSD vertically * USER IMAGE...

  • Page 24: Factory Mode

    3. Setting 3.4 Factory Mode FACTORY mode – Press left button for 5 seconds  IMAGE  PARK Change image location * PARK ENABLE *H-POSITION : Move image horizontally * PARK SETUP * V-POSITION : Move image vertically * REAR SELECT * SAFE ENABLE ...

  • Page 25: Rear Parking Guidelines

    3. Setting 3.5 Rear Parking Guidelines FACTORY mode – Press ◀ button 5 seconds long on the remote control.  PARK  PARK - ENABLE * PARK ENABLE : Option to display the parking guide line(Factory reset- OFF) A. PARK ENABLE – ON Display the parking guide line as * PARK SETUP : Adjusting the position of the above...

  • Page 26: Touch Calibration

    3. Setting 3.6 Calibration FACTORY mode – Press left button for 5 seconds 1. Touch Calibration - YES / NO 2. The message will appear for 2 seconds as indicated above. Then, Calibration will be activated.. (Press “┼” mark) . When it is done successfully, it will show success.

  • Page 27: Remote Button Input

    3. Setting 3.7 Remote button Input FACTORY mode – Press left button for 5 seconds 1. First of all, press ◀ button on 2. Picture above shows DVD remote remote controller 2 seconds long control button value input, select or press UP→DOWN→UP→MENU menu you want to save button in order to access Factory (To register DVD remote control...
  • Page 28 3. Setting 3.7 Remote button Input 3. After register, select “INPUT” in OSD Instruction> continued… menu. Then, you press OK button. The message will appear to choose c. The values that you registered will Yes or No. “Yes” means it saves all appear as green text in the marked settings and “No”...

  • Page 29: Trouble Shooting

    4. Trouble Shooting Q. Unable to change mode A. Check connection of Ground cable and IR Cable. Check LED lamp is on, if not check connection of POWER cable. Q. Screen shows only black. A. .Check second LED lamp of the interface is on, if not, check A/V sources connected are working well.
