1 SECURITY TIPS WARNING!!! To reduce the risk of fire, electric shock, or injury to persons, follow these important safety instructions: non-professionals, not to disassemble the light arbitrarily and lighting accessories inside. rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ (to be selected).
Page 3
2 TECHNOLOGY REFERENCE *AC 100-240V 50/60Hz *Power consumption: 100W *LED : 8pcs 10W warm white LED , 50,000 hours *Beam angle:40° *DMX 512 protocol, master/slave, auto , sound *2/4/8 DMX channel modes *LCD display *PowerCon in & out * DMX in & out 3 Board Instruction MENU UP DOWN ENTER...
Page 4
Auto5 Auto6 Auto7 Auto8 TEST Disp.set Display ON/OFF Key lock ON/OFF Disp flash ON/OFF INFO TimeInfo Ttl Hrs XXXXH Power on XXXXH Last Hrs XXXXH Soft Ver Vx.xx MANUAL Dimmer 000-255 Strobe 000-255 Auto 000-255 Speed 000-255 Factory Set Calibration Set W1 Fine 0-255 W2 Fine...
4 DMX CHANNEL SHEET 2 Channels CH Function Description Value Dimmer 0-255 Intensity 0 to 100% Shutter/Strobe 0-31 Led turn off 32-63 Led turn on 64-95 Strobe effect slow to fast 96-127 Strobe effect slow to fast 128-159 Pulse-effect in sequences 160-191 Led turn on 192-223...
Page 6
45-74 Auto2 75-104 Auto3 105-134 Auto4 135-164 Auto5 165-194 Auto6 195-224 Auto7 225-255 Auto8 Auto Speed 0-255 Auto speed from fast to slow 8Channels Function DMX Value Description LED1 0-255 Intensity 0 to 100% LED2 0-255 Intensity 0 to 100% LED3 0-255 Intensity 0 to 100%...
Page 7
Warranty Card Name Model Production Purchase Sale Store End User Link man: Company Name: Tel: Stamp Add: Description: These must be truthfully fill, seal by the end-user and point-of-sale, or else the warranty will not work (warranty period and terms, see the following) warranty period:one year since purchase warranty terms:1、If fail when using the product in normal state, you can made under the provisions of the warranty, show the warranty card and purchase bills(copy), and enjoy free maintenance service in a specific service center or...
