Summary of Contents for leahua 36pcs 3w LED Par
- Page 1 LH-D002 36pcs 3w LED Par User Manual This manual contains important information. Please read before operating fixture. Add：A-33 Huanan Comprehensive Industrial Zone,Jiaoxin Villiage ,ShiJing Town,BaiYun district,Guangzhou China Tel：+86 020-61162042 Fax：+86 020-61167566...
-
Page 2: Security Tips
1 SECURITY TIPS WARNING!!! To reduce the risk of fire, electric shock, or injury to persons, follow these important safety instructions: non-professionals, not to disassemble the light arbitrarily and lighting accessories inside. rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ (to be selected). - Page 3 2 TECHNOLOGY REFERENCE Voltage: AC100-260V Frequency: 50Hz/60Hz Consumption: 50W（120W） Lamp: 1W/3W*36pcs LED lamp（R12、G12、B12） Channel: 7CH Mode of control: DMX512, automatic, voice active. Function: Can make magic, color mixed, charming effect Packing size: 290*290*410mm Gross weight: 4.5KG 3 Board Instruction Sound and run process Description: Sound：So01 - ----- Seven color jumped change So02 -- ---- Seven color strobe transition Run：...
-
Page 4: Dmx Channel Sheet
P31~P33 --- Seven color gradient P34~P36 --- RGB Chase 4 DMX CHANNEL SHEET Channel Channel Function Value 1channel 0--255 R G B Tune ON/OFF Red (0%--100%) Green lasting lighted， From dark to 2channel 0--255 bright Green (0%--100%) Green lasting lighted，From dark 3channel 0--255 to bright... - Page 5 6 CONNECTION OF DMX-512 AND CONNETION WITH THE LIGHT EQUIPMENT Please connect XLR-XLR control wire with every light from the output of DMX. XLR connection : ATTENTION: Please do remember to connect one circle circuit plug on the output signal of last equipment. And this circle circuit plug was connected a 120ohm resistance between terminals 2 and 3 of the CANON plug, connect this circle circuit plug can avoid the signal flash phenomena of signal DMX512 during the transmission.
-
Page 6: Maintenance
7 Maintenance Problems Check list Trouble Shooting The fixture do 1. If your power as same as the input 1. Make sure the voltage. not work of the machine. 2. Replace the same fuse. 2. If the fuse was broken. LED dimmed If your power us same as the input Make sure the voltage... - Page 7 Warranty Card Name Model Production Purchase Sale Store End User Link man: Company Name: Tel: Stamp Add: Description: These must be truthfully fill, seal by the end-user and point-of-sale, or else the warranty will not work (warranty period and terms, see the following) warranty period：one year since purchase warranty terms：1、If fail when using the product in normal state, you can made under the provisions of the warranty, show the warranty card and purchase bills(copy), and enjoy free maintenance service in a specific service center or...
