Essential SmartBright LED Downlight
DN028B
Mounting Instruction
AS/NZS
IP20
60598
Product Type
DN028B LED12/WW PSU II D150 CAU
DN028B LED12/NW PSU II D150 CAU
DN028B LED15/WW PSU II D175 CAU
DN028B LED15/NW PSU II D175 CAU
DN028B LED20/WW PSU II D200 CAU
DN028B LED20/NW PSU II D200 CAU
DN028B LED8/WW PSU II D90 TB
DN028B LED8/NW PSU II D90 TB
DN028B LED8/WW PSU II D125 TB
DN028B LED8/NW PSU II D125 TB
Unit: mm
Philips Lighting Luminaires (Shanghai) Co., Ltd.
Address: 2F, Building 6, No. 1805, Huyi Highway, Malu Town, Jiading
District, Shanghai, P.R. China
Postal code: 201801
CCT (K)
Power (W)
3000
15
4000
3000
18
4000
3000
23
4000
3000
10
4000
3000
10
4000
DN028B LED12/WW PSU II D150 CAU
DN028B LED12/NW PSU II D150 CAU
DN028B LED15/WW PSU II D175 CAU
DN028B LED15/NW PSU II D175 CAU
DN028B LED20/WW PSU II D200 CAU
DN028B LED20/NW PSU II D200 CAU
Terminal
block
DN028B LED8/WW PSU II D90 TB
DN028B LED8/NW PSU II D90 TB
DN028B LED8/WW PSU II D125 TB
DN028B LED8/NW PSU II D125 TB
Indoor
use only
LEDs
Lumen Output (lm)
58
1200
0.37
81
1500
0.44
112
2000
0.54
40
800
0.2
46
800
0.31
Unit: mm
a
b
Ø A (mm)
Ø B Cut out (mm)
Ø175
150~155
Ø200
175~180
220-240V
Ø225
200~205
Ø115
90~95
Ø150
125~130
Terminal block
c
V1.0
Voltage
Frequency
50/60Hz
~
