Millitronic MG360 Driver Installation & User Manual

Hide thumbs Also See for MG360:
Table of Contents

Advertisement

Quick Links

Download this manual
MG360 Driver Installation & User Manual
Supervised by MILLITRONIC Co., LTD
April, 2019
Version:6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MG360 and is the answer not in the manual?

Questions and answers

Related Manuals for Millitronic MG360

Summary of Contents for Millitronic MG360

  • Page 1 MG360 Driver Installation & User Manual Supervised by MILLITRONIC Co., LTD April, 2019 Version:6...

  • Page 2: Introduction

    WiGig USB3.0 network adapter in the world, which is compatible with MG360 IEEE 802.11ad spec. Trademarks ™ MILLITRONIC CO., LTD Logo are owned by MILLITRONIC CO., LTD Any non MILLTRONIC trademarks are used for reference purposes only.

  • Page 3: Table Of Contents

    Question: What it means it shows without Wi-Fi icon at "Network & Internet settings" panel as below after I insert MG360 device? ............................. 19 Question: How do I check the installation of the MG360 driver? ................20 Question: How to Uninstall Our Driver? ......................... 22 Question: How to set the router for 60GHz WiGig works ..................
  • Page 4 Check Device Manager ............................28 Check the position of the router ........................31 Check the setting of the router .......................... 31...

  • Page 5: Overview

    Overview Product Description MG360 receives high-speed,60 GHz WiGig 802.11ad wireless connectivity for the router devices with up to 2.0 Gbps connection to the router. Complemented by a Wi-Fi router supports 802.11ad, it enables wire-equivalent user experience for wireless usage. This adapter supports the fastest Wi-Fi technology for networking accessibility.

  • Page 6: Adapter Specification

    Adapter Specification Wireless IEEE 802.11ad compliance Adaptive 360 Degree Beamforming 60GHz Radio, 2.0 Gbps* Working range 10 feet (3 meter) Dimension Size: 110.3 x59.3 x17.3 mm Weight: 65 g DRIVER SUPPORT Windows 10, 64-bit RS3 v1709 above only CONNECTION INTERFACE USB 3.0 Type A *Maximum wireless signal rate derived from IEEE 802.11ad specifications.

  • Page 7: Effective Area

    The effective range between MG360 USB adapter and WiGig router is shown in the following figure. Please keep MG360 in the fan area, which has a radius is 3 meters and field of view 150-degree from the center of router on the horizontal plane and under 1-meter difference on the vertical plane.

  • Page 8: Special Notification For Netgear X10 R9000

    R9000 higher at the edge of the table and facing to an open space. The dongle must be within a 150-degree sector region relative to the front side of R9000. Make sure there is no object placed between MG360 and R9000.

  • Page 9: Chapter 1 - Driver Installation

    The MG360 driver had pre-load to internal storage When MG360 has been inserted to the laptop, the USB driver should enable and display the storage automatically, then you can follow the steps mentioned below. If not, please check the “CD Drive“ in ”This PC”.

  • Page 10: Step 2 - Start To Install

    Step 2 - Start to install After executing “setup.exe”, it will guide you to install the WiGig driver. Click “Yes” to continue the installation. Please Click “Install” to start the installation.

  • Page 11: Step 3 -Install Peraso Driver

    Step 3 -Install Peraso Driver This is to install the WiGig driver when we ensured the existence of MG360. The installer would check if you had installed previous versions before this driver installed. Please be patient with completing installation. The installer would check our dongle if plugging on your machine.

  • Page 12: Step 4 -Installation Complete

    Step 4 -Installation Complete Click “OK” to close this window and complete the installation.

  • Page 13: Chapter 2 - User Manual

    Chapter 2 – User Manual MG360 Connect to the router This is an example for using MG360 to connect to the Netgear router. At first, Click the icon in the notification area, then the “Wi-Fi” panel would appear. Select your router from the list of available devices.
  • Page 14 2.3: Click "Connect"; It needs a password to connect in secured mode, but not in open mode. 2.4: If you can see "Connected" as below, it means that it has connected. Fig.2.3 Fig.2.4...

  • Page 15: Federal Communication Commission Interference Statement

    Federal Communication Commission Interference Statement Millitronic MG360 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 16: Appendix: Light Signals

    Appendix: Light Signals In USB 3.0 Port Green Blue Gray Ready to Use Connecting Error No power In USB 2.0 Port 2 Green + Red 2 Green + Blue Ready to Use Connecting...

  • Page 17: Appendix2: Safety Information

    Appendix2: Safety Information (1) This product can only be used in rooms at 26 degrees Celsius (Fahrenheit 78.8), please do not use the product in a non-ventilated place. (2) Avoid covering the machine covered when the machine is in use. (3) Pull out from the bottom when removing the dongle...

  • Page 18: Appendix 3: Frequently Asked Question

    Answer: Yes, but you have to notice the radio of Wi-Fi you want to connect. The radio of some Wi-Fi devices is 2.4Ghz or 5GHz and the radio of MG360 is 60GHz. MG360 is compatible with the same radio of the routers...

  • Page 19: Question: How Could I Do When It Shows "No Wi-Fi Networks Found" As Below

    Question: How could I do when It shows "No Wi-Fi networks found" as below? Answer: Please check the installation of the MG360 driver and follow "Chapter 2". Also make sure the light signal is the green light. Question: What it means it shows without Wi-Fi icon at "Network & Internet settings"...

  • Page 20: Question: How Do I Check The Installation Of The Mg360 Driver

    Question: How do I check the installation of the MG360 driver? "Apps and Features". Both Answer: Recommend two options to check the installation by "Device Manager" or of them are listed on the same menu which appeared you move your mouse hovered on Microsoft's Flag and then click right-button of your mouse.
  • Page 21 In “Device Manager”, If the driver is not installed, it will appear "Unknown device" on the list. In “Apps & features”, key in "Peraso" in search-bar field, you will see the result as below. If the driver is installed, two items of the result will appear on the list.

  • Page 22: Question: How To Uninstall Our Driver

    Question: How to Uninstall Our Driver? Answer: Open "App and Features" Panel. When your mouse hovered on Microsoft's Flag, the menu will appear as below. Click right-button of your mouse, you will see the sub-menu. Then choose "Apps and Features".
  • Page 23 Key in "Peraso" in search-bar field, you will see the result as below: Select "Peraso 60 GHz Wireless Driver", and click "Uninstall". After it has been done, you will see both of them have been removed.

  • Page 24: Question: How To Set The Router For 60Ghz Wigig Works

    Question: How to set the router for 60GHz WiGig works Answer: For example, there is the following instruction for Netgear R9000 router 1. Connect Cat6 cable to wan port (yellow) of R9000 and ethernet Turn on the switch of led 3.
  • Page 25 4. Connect the router with Wi-Fi (2.4GHz or 5GHz) or ethernet cable, and check connection Launch a web browser http://www.routerlogin.net http://www.routerlogin.com and type A login window of Netgear opens. “192.168.1.1”. Refer to https://kb.netgear.com/980/How-do-I-log-in-to- my-NETGEAR-home-router for detail. Please note that, if your router is set into AP mode, you may fail to access the login page.
  • Page 26 7. Click “Wireless” section at home page You can see the information of “60GHz 802.11ad”. Check and save the password of WPA2-PAK in 60GHz information.
  • Page 27 9. After MG360 WiGig driver installation for your laptop, you will be able to scan the 60GHz signal of the router automatically 10. Click the “Connect” button and enter the password shown in 60GHz WPA2-PSK of Netgear R9000 11. If you are the first time to login your router, please refer to...

  • Page 28: Trouble Shooting

    ⚫ Check Device Manager Check http://www.millitronic.com.tw/support/ Question: How do I check the installation of the MG360 driver for driver update. Make sure there is Peraso device in Device Manager. Do not modify advanced setting. The installation pair the laptop and the dongle. So, if you have more than...
  • Page 29 Make sure the Win10 version is 64bit and Rastone3 1709 later. As the following Make sure there is Peraso device in Device Manager.
  • Page 30 Double click Peraso device in “Network adapter”. Click “Advanced”. Make sure “A-MSDU” and “Jumbo Packet” are off.
  • Page 31 ⚫ Check the position of the router Refer to Question: Where can I position the router Special notification for Netgear x10 R9000. Let the dongle face to the front (yellow part of the image below) of the Netgear R9000. Ensure that no objects are between the router and the dongle.
