Arconic MARSON MP-4V Manual

MP-4V Heavy Duty Riveter / 39048
This newly designed heavy-duty air/hydraulic riveter is
ergonomically designed with the professional in mind. The
lightweight 3.7 lbs. well balanced MP-4V includes a Vacuum system
and is designed to maximize a 1" stroke and 3,420 lbs. of pulling
force with a 3 jaw setup that gets the job done. The air supply can be
connected directly or you can use the supplied swivel air connector
with the attached hose for operator convenience. Each tool is
supplied with nosepieces to set 5/32"- 1/4" rivets in all alloys. A 1/4"
Monobolt nosepiece is included in addition to adjustment service
wrenches, fluid applicator, spare jaws and an air off/on valve. The
adjustable Vacuum System control knob located on the side of the
tool allows you to control the force of the air needed to hold the rivet
in place or you may operate with the vacuum system turned off.
Recommended air pressure is 85-95 PSI.
Arconic
Fastening
Systems and Rings
1925 N MacArthur Dr.
Suite 200
Tracy, CA 95376
1
