MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 1

FUNCTIONS

1. PTY:
2. TA:
3. AF/REG:
4. EJECT:
5. CD tray:
6. MODE:
7. RELEASE:
8. DISPLAY
9. POWER:
10. SEL (MULTIJOG): Settings of volume, bass, trebles, balance and fader
11. ^ :
12. v :
13. BND/LOU:
14. Station keys 1-6
15. DSP/0:
16. -<< :
17. +>>:
18. AMS/MP3:
19. P. EQ:
20. PAU:
21. SCN:
22. RPT:
23. SHF:
24. –
25. –
26. Red LED
27. RESET:
GB 2
Programme Type Code
Includes programmes such as news, music, sport, etc., dependent on
the radio station.
Traffic Announcement Identification. Identification data on traffic
announcements that can be broadcast.
To switch on the RDS mode and/or the regional programme mode
CD eject
To load the CD
Switch-over radio/CD/MP3/number key 7
Removal of operating panel
On/Off switch
Increase volume
Reduce volume
Selection frequency range/loudness
To scan settings of programme, time, frequency and PTY/number key 0.
Tune/station search
backwards/number key 8
Tune/station search
forwards/number key 9
Automatic station memory / switch-over
frequency display/station name
Equalizer
Pause button (for CD/MP3)
Scan button (plays the CD track/MP3 for approx. 10 sec.)
Repeats a track (CD/MP3)
Random Playback (CD/MP3)
(Theft protection LED)
Reset to the works settings
C
M
Y
CM
MY
CY CMY
K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD 4295 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Medion MD 4295

Summary of Contents for Medion MD 4295

  • Page 1: Functions

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 1 CY CMY FUNCTIONS 1. PTY: Programme Type Code Includes programmes such as news, music, sport, etc., dependent on the radio station. 2. TA: Traffic Announcement Identification. Identification data on traffic announcements that can be broadcast.

  • Page 2: Safety Precaution

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 2 CY CMY SAFETY PRECAUTION • Place the unit into the corresponding slot or choose a place where it can be installed without impeding the driver in his usual driving job. • Shortly connect the cables before finally installing the unit. Make sure that they are correctly connected and that the system works properly.

  • Page 3: Table Of Contents

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 3 CY CMY CONTENTS FUNCTIONS...........................2 SAFETY PRECAUTION.........................3 BEFORE SWITCHING ON......................5 INSTALLATION..........................5 INSTALLATION OF THE RADIO IN THE ISO SLOT OF YOUR CAR..........5 • Detaching and attaching the operating panel................6 ISO ADAPTER PLUG ........................6 •...

  • Page 4: Before Switching On

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 4 CY CMY BEFORE SWITCHING ON Remove in any case both transport securing screws at the upper radio housing before starting with the installation (marked by red flags)! transport secuting device INSTALLATION This car radio is simple to install in every standard ISO radio slot.

  • Page 5: Detaching And Attaching The Operating Panel

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 5 CY CMY DETACHING AND ATTACHING THE OPERATING PANEL Press the RELEASE button (7) and remove the operating panel. Always keep the operating panel in the transport bag supplied with the unit.

  • Page 6: Cable Connections

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 6 CY CMY CABLE CONNECTIONS for a four-speaker (quadro) system REAR OF CAR RADIO Aerial connection Ignition switch (B+) Important notes! Memory Memory back-up pink RCA cable right red Back-up Earth must be connected...

  • Page 7: Basic Operation

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 7 CY CMY BASIC OPERATION • Switching on / off Press the PWR button (9) to switch on/off the unit. • Volume Adjust the volume by pressing buttons ^ (11) and v (12).

  • Page 8: Radio

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 8 CY CMY RADIO • Selecting the frequency range Press the LOU/BND button (13) to change between VHF (F1, F2, F3), medium wave (MW) and long wave (LW). You can memorise six radio stations in each band.

  • Page 9: Regional Programme Mode

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 9 CY CMY • Regional Programme Mode Some stations broadcast different regional programmes. To select only the alternative frequencies of the desired regional programme keep the AF/REG button (3) pressed for some time until a signal sound will be audible to switch the mode on or off.

  • Page 10: Rds (Radio Data System)

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 10 CY CMY • RDS (Radio Data System) RDS is a service of the radio stations. Besides the usual music and text pieces, additional information is broadcast in form of encoded digital signals which can be evaluated by the car radio.

  • Page 11: Cd Player

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 11 CY CMY CD-PLAYER • Inserting and removing of CDs Insert the CD in the slit (5). CD playback starts. The display shows S--CDP (i.e. "search track"). To remove the CD, press the EJECT button (4).

  • Page 12: Mp3 Playback

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 12 CY CMY MP3 PLAYBACK The playback starts automatically when a MP3 CD-ROM is inserted. You find the individual key functions in the chapter CD Player. You can directly select the track or interpreter. Please take into account that most of the MP3 functions are dependent on the type of creation of the MP3 CD.

  • Page 13: Keys Table Of Allocations

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 13 CY CMY • Table keys of allocations AMS/MP3 (18) Select settings BND/LOU (13) Confirm 1 (14) A, B, C, 1 2 (14) D, E, F, 2 3 (14) G, H, I, 3...

  • Page 14: Troubleshooting

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 14 CY CMY TROUBLESHOOTING Problem Cause Solution The unit cannot be switched on. The ignition is not switched on. Switch on the ignition by turning the key. The fuse is defect. Change the fuse.

  • Page 15: Specifications

    MD 4295 Autoradio BDA_GB 06.12.2002 12:27 Uhr Seite 15 CY CMY SPECIFICATIONS General Operating voltage: DC 12V, negative earth connection Housing dimensions: 178 x 155 x 50mm (WxDxH) Power: Peak music power output 4 x 25W R.M.S. Fuse: 0.5 Ampere (red), 15 Ampere (pink)
