Instructions
G3 Illuminated
Remote Run
Button Kit
Used for remote indication of pump state and to initiate a manual lube operation. For
professional use only.
Kit Nos.*: 12 Volt - 571030, 571032; 24 Volt - 571031, 571033
*All Kits rated IP65.
Important Safety Instructions
Read all warnings and instructions in this
manual and the G3 Pump instruction manual
included with your unit. Save these instructions.
Parts Included in Kits
Item
No.
Description
BUTTON, push, 12 V, Kits 571030,
1
571032; 24 V, Kits 571031, 571033
2
CONNECTOR, quick
3
LABEL, run
HARNESS, wiring, M12 to bare
4
wire, models 571032, 571033
5
O-RING
1
5
4
Qty
1
4
1
1
1
3A0528E
ENG
3
2
Advertisement
Summary of Contents for Graco 571032
- Page 1 3A0528E Used for remote indication of pump state and to initiate a manual lube operation. For professional use only. Kit Nos.*: 12 Volt - 571030, 571032; 24 Volt - 571031, 571033 *All Kits rated IP65. Important Safety Instructions Read all warnings and instructions in this manual and the G3 Pump instruction manual included with your unit.
- Page 2 (4) to connector location on G3 pump identified with symbol to the right. (See wiring diagram, page 4.) NOTE: For 5-wire power cable installations (Graco Part No. 123750, sold separately), connect end of Testing Installation wiring harness to CPC power input. (See wiring dia- gram, page 4.)
- Page 3 Testing Manual Run 5-Wire CPC Power Cable 1. Power up G3 and enter Press remote run button and verify light turns green and Setup Mode by pressing unit has entered the lube cycle. both the UP and DOWN ARROW buttons together for 3 seconds.
-
Page 4: Wiring Diagrams
All written and visual data contained in this document reflects the latest product information available at the time of publication. Graco reserves the right to make changes at any time without notice. Original instructions. This manual contains English. MM 3A0528...
