- Page 1 User Manual Soundcore Rave A3391 Safety Instructions ① Avoid dropping. ② Do not disassemble. ③ Avoid extreme temperatures. ④ Do not use the device outdoors during thunderstorms. ⑤ Use original or certified cables. ⑥ Do not use any corrosive cleaner / oil to clean. What’s Included...
- Page 2 At a Glance ① Central Volume Knob (For speaker volume control) ② Power Button / Power Indicator ③ Source Input Button / Source Input Indicator ④ Bluetooth Button / Bluetooth Indicator ⑤ Previous Track Button ⑥ Multi-function Button ⑦ Next Track Button ⑧...
- Page 3 13. Mic Input 14. Audio IN 15. Audio OUT USB Port 17. Power IQ USB Port Using Your Soundcore Rave 1. Turn On / Off Press and hold for 1 second Press and hold for more than 2 seconds a. Bluetooth Mode...
- Page 4 Note: Soundcore Rave can pair up to 2 mobile devices via Bluetooth(Dual Bluetooth Connection). Bluetooth Pairing Mode Flashing Blue Connected to a device Solid Blue 改图：实心黑圈 Enter True Wireless Stereo Group Mode / Disconnect True Wireless Stereo...
- Page 5 True Wireless Stereo Group Mode Double Flashing Blue Connected to True Wireless Stereo Solid Blue 改图：实心黑圈 With True Wireless Stereo technology, you can pair your Soundcore Rave with another Soundcore Rave to explore the best sound effects with left and right sound channels separated on both speakers.
- Page 6 Play Next Song Play Previous Song Press to turn Bass Up on and off Press and hold for 2 seconds to switch between Indoor / Outdoor modes. Activate Siri / Other Voice Control Software Volume Up / Down Check available Light Effects modes on Soundcore App. When turned on, Soundcore Rave will automatically connect to the last connected device if available.
- Page 7 mode. To pair a different device, press the Bluetooth button to re-enter pairing mode. Then repeat the pairing steps. Having connection problems? Remove Soundcore Rave from your device’s Bluetooth history and ensure it’s less than 3 feet away. Then try pairing again. To get the best sound quality, make sure there is a clear line of sight between the connected device and your speaker.
- Page 8 USB mode Solid White(Source input indicator) *SoundLine AUX cable sold separately. When using AUX mode, control audio playback via the connected device. c. Connect Multiple Rave Speakers Soundcore Rave can connect to other Soundcore Raves via RCA cables to form a wired party chain.
- Page 9 Connect the microphone to MIC IN port. You can adjust the microphone volume by turning the MIC ECHO volume knob. 3. Charging your Soundcore Rave Battery level <10% Battery level <25%...
- Page 10 Battery level 25%~55% Battery level 51%~75% Battery level 75%~100% Charging Slow Flashing White(Power indicator) You can charge your mobile device through the Power IQ USB port on Soundcore Rave. Use the included AC power cable to charge your Soundcore Rave and make sure it is fully charged before its first use.
- Page 11 Disconnect your speaker from the charger when fully charged. Do not charge your speaker for extended periods. 4. Beat-Driven Light Show Press to turn Light Effects On / Off Note: Flash can be turned off in Soundcore app individually. 5. Soundcore App Download the Soundcore app for an enhanced product experience.
- Page 12 Limited Warranty. Declaration of Conformity Hereby, Anker Innovations Limited declares that the radio equipment type A3391 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.anker.com/products...
- Page 13 Size 255 x 245 x 505 mm Weight (without packaging) 8.37 kg / 295.2 oz Bluetooth version V5.0 Bluetooth range 20 m / 66 ft Apple and the Apple logo are trademarks of Apple Inc. Google Play and the Google Play logo are trademarks of Google Inc. Product Number A3391 Bluetooth Speaker / Soundcore Rave...
- Page 14 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two con ditions: (1) This device may not cause harmful interference, and (2) this device must accept any i nterference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance co uld void the user's authority to operate the equipment.
- Page 15 re environnement. ce matériel doit être installé et exploité à une distance minimale de 20 cm entr e le radiateur et votre corps. Important Safety Instructions 1.Please read this owner’s guide carefully and save it for future reference. 2.To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. 3.Do not place naked flame sources, such as lighted candles, on or near the product.
