图纸名称 PART NAME
林芳芳
设 计
2017.04.27
DESIGN
校 对
蒋卨敏
CO.BY
标准化
STANDARD
业务
许岩
seller
批 准
AUTHORIZE
技术要求
1.
尺寸：32K；
2.
说明书印刷颜色：单色；
3.
样板需送设计部门封样；
4.
制件必须满足QMB-J53.005 产品说明书及其它类似印刷件技术规范。
5.
需要符合美的冰箱事业的最新版《QMB-GC08.007 有害物质管理规定》的限值要求。
标记
MARKER
①
②
③
④
⑤
说明书最后一页添加条码
条码仅供参参考，实际扫码按正确的14位新物料编码生成(文字部份固定不变，前后无空格，黑色印刷）
码制与其它要求按冰箱事业部最新公文要求
SIZE:60*20mm
xxxxxxxxxxxxxx:14
说明书递交文档
LEC TF55207W(CE-BCD275WM-SQ)
说明书
图样标记
版本号
REL
REV.NO.
0
共
页
TOTAL SHEETS
变更内容
重量(g)
比例
WEIGHT
scale
第
页
NO. OF SHEETS
图号/物料编码 PART NO.
1111
材料 MATERIAL
80g双胶纸
美的冰箱事业部
MIDEA REFRIGERATION DIVISION
修改日期
签名
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lec TF55207W
Summary of Contents for Lec TF55207W
- Page 1 说明书递交文档 图纸名称 PART NAME 林芳芳 设 计 图号/物料编码 PART NO. 2017.04.27 DESIGN LEC TF55207W(CE-BCD275WM-SQ) 1111 校 对 蒋卨敏 说明书 CO.BY 标准化 材料 MATERIAL STANDARD 80g双胶纸 图样标记 版本号 重量(g) 比例 业务 许岩 REV.NO. WEIGHT scale seller 批 准 AUTHORIZE 美的冰箱事业部 共...
- Page 2 TF55207W...
-
Page 4: Table Of Contents
Contents Safety Warnings ........................... 4 Unpacking ............................ 6 Installation ........................... 7 Location ..................................7 Levelling the Unit ..............................7 Free Space Requirements ........................... 7 Reversing the Door Swing ........................... 8 Cleaning Before Use ............................13 Before Using Your Unit ............................13 Product Overview ........................14 Operation ........................... -
Page 5: Safety Warnings
Safety Warnings For your continued safety and to reduce the risk of injury or electric shock, please follow all the safety precautions listed below. • Read all instructions carefully before using the unit and keep them for future reference. • Retain the manual. If you pass the unit onto a third party, make sure to include this manual. - Page 6 • Do not store bottles or glass containers in the freezer compartment. bottle and damage your freezer compartment. (If applicable) WARNING • Keep ventilation openings in the unit enclosure or in the built-in structure clear of obstructions. • Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
-
Page 7: Unpacking
Thank you for purchasing your new LEC Fridge Freezer. We recommend that you spend some time reading this instruction manual in order that you fully understand all the operational features it offers. Read all the safety instructions carefully before use and keep this instruction manual for future reference. -
Page 8: Installation
INSTALLATION Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated with an average room temperature of between 16°C and 43°C. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption. -
Page 9: Reversing The Door Swing
INSTALLATION Reversing the Door Swing Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner • Ensure the unit is unplugged and empty. • All parts removed must be saved to do the reinstallation of the door. • Do not lay the unit flat as this may damage the coolant system. •... - Page 10 INSTALLATION before finally tightening the hinge.
- Page 11 INSTALLATION with the needs time...
- Page 12 INSTALLATION with the needs time...
- Page 13 INSTALLATION with the needs time...
-
Page 14: Cleaning Before Use
INSTALLATION Cleaning Before Use Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water using a sponge or cloth. Wipe completely dry before replacing the shelves, drawers and salad bin. Clean the exterior of the unit with a damp cloth. If you require more information refer to the Cleaning section. -
Page 15: Product Overview
Product Overview Thermostat dial Upper tray Light Glass shelf Vegetable basket Lower tray Flap Freezer drawer Adjustable feet Egg Tray Ice Tray... -
Page 16: Operation
Operation Switching On Your Unit • Connect the mains cable to the mains socket. • The internal temperature of your fridge compartment is controlled by the Thermostat Control. • The unit may not operate at the correct temperature if it is in a particularly hot or a particularly cold room, or if you open the doors often. -
Page 17: Noises Inside The Unit
Noises Inside the Unit! You may notice that your unit makes some unusual noises. Most of these are perfectly normal, but you should be aware of them! These noises are caused by the circulation of the refrigerant liquid in the cooling system. It has become more pronounced since the introduction of CFC free gases. -
Page 18: Preparations For Freezing
Preparations for Freezing • Use quality food and handle it as little as possible. Freeze food in small quantities as it freezes faster, takes less time to defrost and enables you to control the quantity you need better. • Leave cooked food to cool completely. Chill food before freezing if possible. •... -
Page 19: Cleaning
Cleaning Defrosting The freezer compartment of this unit is frost-free. With proper use, there should not be any frost accumulated. However, in case of improper use of the freezer compartment, frost might build up in the freezer compartment after the unit has been used for a period of time. Scrape away the frost using a plastic scraper (not included). -
Page 20: Maintenance
Maintenance Changing the Internal Light The internal light is an LED light. It cannot be changed by the user; please contact your service agent. Care When Handling / Moving the Unit Hold the unit around its sides or base when moving it. Servicing The unit should be serviced by an authorised engineer and only genuine spare parts should be used. - Page 21 Product fiche concerning the "COMMISSION DELEGATED REGULATION (EU) No 1060/2010" Trade mark: LEC Moder Identifier: TF55207W Category of the household refrigerating appliance model: Refrigerator-freezer Energy efficiency class: A+ Energy consumption 281 kWh/annum, based on standard test results for 24 hours. Actual energy consumption will depend on how the appliance is used and where it is located.
