- Page 1 USER GUIDE TL6015W TL6018W 60cm Larder...
- Page 2 Thank you for buying this high quality appliance This handbook is designed to help you through each step of owning your new appliance, from installation to use. Please read through this handbook carefully before you start using your appliance, as we have endeavoured to answer as many questions as possible, and provide you with as much support as possible.
-
Page 3: Table Of Contents
REVERSING THE DOOR ..................9 CHANGING OF DOOR OPENNING DIRECTION ..........12 CHAPTER 5. BEFORE CALLING SERVICE ............13 CHAPTER 6. THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ....................16 LEC CUSTOMER CARE ..................19 UK - 2 -... -
Page 4: Chapter 1. Before Using Your Fridge
CHAPTER 1. BEFORE USING YOUR FRIDGE Safety Instructions • Please read this booklet thoroughly before installing and switching on the appliance. The manufacturer accepts no responsibility for incorrect installation and use. • If this appliance is to replace an old one equipped with a lock, break or remove the lock as a safety measure to avoid children becoming trapped inside. -
Page 5: Warnings
Warnings • Do not defrost the appliance with other electrical devices (i.e. hair dryer) or any arti cial means and do not use sharp metal objects to remove the ice on the freezer, as this could cause damage to the refrigerant system. •... -
Page 6: Installing And Operating Your Fridge
Installing and Operating your Fridge The climate class of this appliance is Class N with an ambient temperature range of +16°C and +32°C, the appliance should be sited within this ambient range. The appliance may not operate consistently (possibility of defrosting contents or temperature becoming too warm in the frozen food compartment) if it is sited for extended periods of time below the cold end of the climate class temperature range for which the appliance is designed. -
Page 7: Chapter 2. How To Operate The Appliance
CHAPTER 2. HOW TO OPERATE THE APPLIANCE Thermostat Setting Larders (coolers) have not any freezer compartment but can cool below 5°C. • The thermostat automatically regulates the inside temperature of the refrigerator compartment. Temperature settings are 1 to 5 - with 5 being the coldest. •... -
Page 8: Food Storage In The Appliance
Food Storage In The Appliance • The refrigerator compartment is used for storing fresh food for a short period of time. • Do not place food in direct contact with the rear wall of the refrigerator compartment. Leave some space around food to allow circulation of air otherwise frost could form on food. •... -
Page 9: Chapter 3. Cleaning And Maintenance
CHAPTER 3. CLEANING AND MAINTENANCE Cleaning • Switch off and disconnect the appliance from the power supply before cleaning. • Do not pour water into the appliance. • The refrigerator compartment should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water. •... -
Page 10: Chapter 4. Shipment And Repositioning
CHAPTER 4. SHIPMENT AND REPOSITIONING Shipment • Original package and foam may be kept for re-transportation (optional). • You should fasten your fridge with thick package, bands or strong cords and follow the instructions for transportation on the package for re-transportation. •... - Page 11 UK - 10 -...
- Page 12 UK - 11 -...
-
Page 13: Changing Of Door Openning Direction
CHANGING OF DOOR OPENNING DIRECTION 1a-) Unscrew top and bottom screws of head panel. 1b-)Take the head panel off. 1c-) Cut the opposite side of the head panel throughout the traced line. 2a-) Unscrew the screws of top hinge. 2b-) Take the door off. 2c-) Unscrew the pin of the top hinge and assemble it to the opposite one. -
Page 14: Chapter 5. Before Calling Service
CHAPTER 5. BEFORE CALLING SERVICE If your refrigerator is not working properly, it may be a minor problem, therefore check the following. If the appliance does not operate check that ; • There is not a power failure. • The main plug is properly plugged in and is not loose. •... - Page 15 IMPORTANT NOTES: • Compressor protection function will be activated after sudden power breakdowns or after unplugging the appliance, because the gas in the cooling system is not stabilized yet. Your fridge will start after 5 minutes, there is nothing to worry about. •...
- Page 16 Supplier's name or trade mark Model / Item TL6015W Type of appliance GN325K.TUR The energy ef ciency class Voltage 220-240V / 50HZ Power 95 W Energy consumption 0,459 kw / 24h Net storage volume of fresh food 284 lt Net storage volume of frozen food...
-
Page 17: Chapter 6. The Parts Of The Appliance And The Compartments
CHAPTER 6. THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS TL6018W This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model. 1) HEAD PANEL 2) LIGHT BULB 3) TURBO FAN (GLASS SHELF MODELS) 4) GLASS SHELVES (OPTIONAL WITH WIRE SHELVES) 5) TOP CRISPER COVER(SAFETY GLASS*) (OPTIONAL) 6) TOP CRISPER(OPTIONAL) - Page 18 TL6015W This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model. 1) HEAD PANEL 2) LIGHT BULB 3) TURBO FAN (GLASS SHELF MODELS) 4) GLASS SHELVES 5) CRISPER COVER(SAFETY GLASS*)
- Page 19 ELECTRICAL CONNECTION (UK ONLY) For your safety please read the following information Warning: This appliance must be earthed. This appliance operates from 220-240 volts and should be protected by a 13 amp fuse in the plug. The appliance is supplied with a standard 13 amp 3-pin mains plug tted with a 13-amp fuse. Should the fuse require replacement, it must be replaced with a fuse rated at 13 amp and approved to BS1362.
-
Page 20: Lec Customer Care
LEC CUSTOMER CARE Please keep this handbook in a safe place. Please ll in the model number and serial number in the spaces provided below as they will assist us should you need to call. 0844 815 3737 When you dial this number you will hear a recorded message and be given a number of options.
