CROMTECH™ FIRE FIGHTING PUMP
OPERATION & INSTRUCTION MANUAL
Thank you for your selection of a Cromtech Fire Fighting Pump
Single Impeller. This Operation Manual explains its use, installation,
checking and maintenance. We highly recommend that you retain
this manual for ready reference regarding its proper handling.
Head Office (08) 9350 5588
SINGLE IMPELLER
Spare Parts & Service
Phone: 1300 554 524
Freecall Fax: 1800 636 281
spareparts@crommelins.com.au
www.crommelins.com.au
Sales 1300 650 659
email@crommelins.com
.au
Advertisement
Table of Contents
Related Manuals for Cromtech TFF150HP
Summary of Contents for Cromtech TFF150HP
- Page 1 CROMTECH™ FIRE FIGHTING PUMP SINGLE IMPELLER OPERATION & INSTRUCTION MANUAL Thank you for your selection of a Cromtech Fire Fighting Pump Single Impeller. This Operation Manual explains its use, installation, checking and maintenance. We highly recommend that you retain this manual for ready reference regarding its proper handling.
- Page 2 Thank you very much for purchasing a Cromtech Fire Fighting Pump – Single Impeller which can be used for domestic farming, fire fighting and general use. This manual covers its operation and maintenance. Please take a moment to familiarise yourself with the proper operation and maintenance procedures in order to maximise the safe and efficient use of this product.
- Page 3 SAFETY This manual contains important information on how to use the Cromtech Fire Fighting Pump – Single Impeller model TFF150HP properly and safely. Please read through this manual before you attempt to operate the machine. This fire fighting pump is designed to give safe and dependable service if operated according to the instructions.
- Page 4 OPERATING INSTRUCTIONS Suction and discharge pipes: To avoid air locks and make priming easy the suction pipe should be laid so that it rises evenly from the water source to the pump. All pipe joints have to be sealed airtight and they should be the same size or larger than the pump inlet and discharge outlet.
- Page 5 TYPE OF WATER If any liquid contains stringy or large material that may cause obstruction, a suction strainer should be used. If the pump is needed for chemicals, you must check the pump compatibility with your local dealer. FIXED INSTALLATIONS In some installations and only if the pump is used under stressful conditions, such as pumping uphill for long distances, the pump may not work on start up.
- Page 6 FIRE FIGHTING PUMP – SINGLE IMPRELLER SPECIFICATION CHART MODEL TFF150HP Inlet (inch) 1 ½” Outlet (inch) 1 x 1 ½” & 2 x 1” Total Head (m) Volume max. (L/min) 360L/min Volume max. (L/hr) 21,600L/HR Max. Suction lift (m) Pump Type...
- Page 7 TROUBLE SHOOTING GUIDE PROBLEM CAUSE SOLUTION 1. Turn engine switch to ON 1. Engine switch in OFF Engine won’t start position position 2. Fill fuel tank or turn on fuel 2. No fuel in engine supply 3. Replace with factory 3.
- Page 8 No. Description Description Casing Outer (Ali Alloy) O’Ring 7x11 Seal Assembly Washer (Stainless) 5/16” Seal Ring, Volute Set Screw, UNF 5/16”x 1 ½ “ Flap Valve Weight (Stainless) Flap Valve Rubber O’Ring 31.5 x 39.5 Flat Valve Washer Screw ¼ “ x ½ “ Cover, Suction (Inlet 1 ½...
