CTS CVT-RACK-16 User Manual

INSTALLATION AUXILIARY FIGURES
Acc ess ories
Power co de
Pullin g cable x 1
Moun t ear x 2
Slider set x 16
Rubber pedest al x 4
Upper and lower slider
of media co nverter
1 2
W hen in stalli n g the media convert er to th e Chas s is ,
pleas e attac h t wo sli de r s to the m edia convert er
first.
1. Tak e off 4 screws f rom the m edia conver ter.
2. Fast en t wo sliders wit h screws in top and
bott om location .
Note:
1. For recent medi a c onv erters , there are 4 reserv ed sc rew holes
on laterals or sliders.
2. If y our media converters are older v ersions , pleas e unsc rew
first (Refer to Point 1).
3. If y our media converters already hav e res erved lateral holes,
please fasten t he s liders direc tly (Refe r to Point 2).
Top view wit h fans locatio n
Unf asten f our screws f or f an re pla cem ent .
Mount Ear
Tak e screws off to rem ove m ount ear
Slide in
Pus h the m edia converte r into CVT-RACK- 16
and fast e n screws on th e slider of med ia
converter.
Fan Replacement
A C 1 0 0 - 2 4 0 V
1.Tak e the f an out f rom CVT-RACK- 16, then
Pull po wer jack et off .
2. Re plac e a ne w fa n, the n pu t po wer jack et back .
3. Pus h the ne w f an back to CVT-RACK-16.
4. Fast en f our sc re ws .
Mount Rack
Fast en scr ew s in rack to fix CVT-RACK-16
Slid e out wit h pulli ng
cabl e
Pull out the m edia converter with the pulli ng
cable.
Po wer Repla ce me nt
1
A C 1 0 0 - 2 4 0 V
2
Rem ove screws f rom two sides of power
suppl y the n pu ll po wer s u ppl y o ut.
AC 1 00 -2 4 0 V AC 1 00 -2 4 0 V
