- Page 1 3.5" BayExtension...
- Page 2 Package Contents (A) 1x 3.5" BayExtension (B) 8x mounting screws for 2.5" HDDs/SSDs (fine thread) (C) 4x mounting screws for the mounting frame (coarse thread) (D) 1x Manual (A) 1x 3.5" BayExtension (B) 8x Montageschrauben für 2,5"-Festplatten/SSDs (Feingewinde) (C) 4x Montageschrauben für Einbaurahmen (Grobgewinde) (D) 1x Anleitung...
- Page 3 Mount index 1 - Screw openings for upper 2.5" HDD/SSD 2 - Screw openings for lower 2.5" HDD/SSD 3 - Mounting frame attachment 1 - Schrauböffnungen für obere 2,5"-Festplatte/SSD 2 - Schrauböffnungen für untere 2,5"-Festplatte/SSD 3 - Befestigung des Einbaurahmens...
- Page 4 Two 2.5" HDDs/SSDs The BayExtension mounting frame allows for the simultaneous installation of up to two 2.5" HDDs or SSDs. Notes: 1. Related to their design mechanical 2.5" HDDs shall not be installed headfirst (please contact the HDD manufacturer for details)! 2.
- Page 5 Mounting 2.5" HDDs/SSDs 1. Place one 2.5" HDD/SSD into the lower mounting bay of the BayExtension mounting frame. 2. Screw this HDD/SSD to the BayExtension mounting frame from underneath using the included fine thread screws. 3. Place a second 2.5" HDD/SSD into the upper mounting bay of the BayExtension mounting frame.
- Page 6 Installing into 3.5" bays The BayExtension mounting frame can be mounted to standard 3.5“ bays or mounting bays for Floppy/card readers of PC cases and is attached with four fine thread screws. 1. Open the PC case. 2. Slide the BayExtension mounting frame with pre-installed HDDs into a 3.5“...
- Page 7 Note Hinweis Legal Disclaimer For potential loss of data, especially due to inappropriate handling, SHARKOON assumes no liability. All named products and descriptions are trademarks and/or registered trademarks of the respective manufacturers and are accepted as protected. As a continuing policy of product improvement at SHARKOON, the design and specifications are subject to change without prior notice.
- Page 8 Sharkoon Technologies GmbH Grüninger Weg 48 35415 Pohlheim Germany © Sharkoon Technologies 2019...
