  • Page 1 ThermoFLUX d.o.o., Bage br. 3, 70101 Jajce, Bosna i Hercegovina, Tel/Fax: 030–648-050 www.thermoflux.ba tfinfo@thermoflux.ba PELLET STOVE USER AND MAINTENANCE MANUAL...

  • Page 3: Table Of Contents

    Basic principles ....................6 2.1.2 Using the stove ....................6 2.1.3 Permissible fuel for the Minitherm - stoves ............6 2.1.4 Recommended wood pellets ................6 Warnings and safety symbols used................. 7 Other risks of the side effects ................8 Duty to inform ....................
  • Page 4 Minitherm - ThermoFLUX 5.3.5 STAND BY mode ................... 21 5.3.5.1 STAND BY mode with installed sensor for air temperature ......... 21 5.3.5.2 STAND BY mode with room thermostat connected ..........22 5.3.6 Option Buzzer ....................22 5.3.7 Filling of spiral dispenser ................. 23 5.3.8...

  • Page 5: Notes On The Manual

    1.1.1 Easy and safe operation This manual contains important information for proper and safe operation of the Minitherm - stoves. Following these instructions you will avoid danger and repair costs, and also increase the operational life of the stove. 1.1.2...

  • Page 6: Safety Notes

    2.1.1 Basic principles Minitherm stove was built in accordance with safety regulations. However, its use can result in the injury or death of the user and/or third part and in impairments to the stove itself or to other material goods.

  • Page 7: Warnings And Safety Symbols Used

    Minitherm - ThermoFLUX 2.2 Warnings and safety symbols used DANGER OF ELECTRIC SHOCK. Work on areas marked with this symbol may only be done by a qualified electrician. WARNING! Warning about a dangerous location. Work on areas marked with this symbol can lead to serious injuries or to extensive material damage.

  • Page 8: Other Risks Of The Side Effects

    Minitherm - ThermoFLUX 2.3 Other risks of the side effects Despite the precautions taken there are also certain risks of side effects: DANGER OF CARBON MONOXIDE. If the stove is running during cleaning time may occur transmission of CO through the open door. Do not open the door longer than necessary.

  • Page 9: Installation And Commissioning Of The Stove

    Commissioning system in the operation is performed by personnel authorized by ThermoFLUX Ltd or autorized seller. Commissioning includes referral to operation with the basic operations and maintenance of the stove. Authorized service for the first start, must control the functioning of the stove at least during one full operating cycle.

  • Page 10: Minimum Distances Of The Stove From Wall And Objects

    Smoke pipe should be installed fixed. It would be good to leave safety gates that could do the Minitherm -r cleaning, especially in their horizontal parts. You should avoid as much as possible horizontal mounting parts. Horizontal parts must have a slope of at least 3% upwards.

  • Page 11: Functional Description

    Minitherm - ThermoFLUX Functional description 4.1 General overview Accompanying material  Tools for the pipeline and firebox cleaning  Door key  Power supply cable  Instructions booklet  Guarantee...

  • Page 12: Technical Data

    Minitherm - ThermoFLUX 4.2 Technical data: Minitherm - Power range 3 - 8,5 Heat transfer to the air Heat in room Air content Recom. draught ratio mbar 0,05/0,1 Air conection return / out inch 3/4'' Flue gas max.temperature cca160 Max working temperature...

  • Page 13: Function Of Stove

    Minitherm - ThermoFLUX Function of stove 5.1 Overview of the controls and display and their basic functions Button Description Increasing temperature and program functions (adjusting days, time...) Decreasing temperature and program functions (adjusting days, time...) Changing – accepting program ON / OFF, program exit...
  • Page 14 Clock Air temperature indicator Regulation on the stoves ''Minitherm'' is most important electronic component. It is consisted of key controling modul set under the cover of the stove and controling unit with display set on the front side of the stove. With controling unit it is possible to control functions of the stove and also to check information about present state of the stove.

  • Page 15: Principle Of Stove Operation

    Minitherm - ThermoFLUX 5.2 Principle of stove operation Principle of the stove operation is very simple. When button for start is pressed stove goes into IGNITION MODE. START is displayed, and after that PELLET IGNITION. Usually this phase lasts for 5-15 minutes depending on type of the stove and pellet quality.

  • Page 16: Schematic Representation Of The Menu Control

    Minitherm - ThermoFLUX 5.3 Schematic representation of the menu control By pressing button SET we enter general menu.
  • Page 17 Minitherm - ThermoFLUX...

  • Page 18: Clock Adjustments

    Minitherm - ThermoFLUX 5.3.1 Clock adjustments Clock adjustments can be done on following way:...

  • Page 19: Adjustments Of The Programmed On And Off Mode

    Minitherm - ThermoFLUX 5.3.2 Adjustments of the programmed on and off mode 5.3.3 Stove has possibi lity f or programme d on and of f mode during a day and this option is regul ated on three ways: 1. DAY PROGRAM, in this mode we can set 2 (two) different times for ignition and shutting down of the stove.This applies to all...
  • Page 20 Minitherm - ThermoFLUX Shema 2. Shema 3. Shema 4.

  • Page 21: Language Options

    Minitherm - ThermoFLUX 5.3.4 LANGUAGE OPTIONS Language settings are adjusted by pressing the SET button,and after that by pressing of button 5 or 6 we choose option MENU 03-LANGUAGE. By pressing of the SET button language menu is opened (italian,english,german,french, croatian...) in which we can choose desired language by pressing button 1 or 2.

  • Page 22: Stand By Mode With Room Thermostat Connected

    Minitherm - ThermoFLUX FUNCTION STAND-BY SET OFF In the case that function STAND BY is not activated (OFF) , and that connection for the room thermostat is not overbridged, stove will always work in power 1 no matter which power is set.

  • Page 23: Filling Of Spiral Dispenser

    Minitherm - ThermoFLUX Option BUZZER is activated by pressing of button SET, and after that with buttons 5 or 6 we choose item MENU 05- OPTION BUZZER. By pressing of the button SET choice ON or OFF is opened (with buttons 1 or 2 we are selecting option and confirmation is done by pressing SET ).
  • Page 24 Minitherm - ThermoFLUX By pressing SET,option for desired type of fuel is opened (PELLET or WOOD).Selection is made by buttons 1 or 2. After choosing of fuel type, confirmation of selection is done by pressing button SET.

  • Page 25: Ignition And Shutting Down Of Stove

    Minitherm - ThermoFLUX Ignition and shutting down of stove Ignition sequence and description of regulation Basic function of the regulation is to secure reliable ignition of used fuel, optimal conditions for combustion and controled sequence for shutting down. Depending on working power, and complexity of the heating system, parameters are read and controled differently.

  • Page 26: Shutting Down Of Stove

    Minitherm - ThermoFLUX After ignition of pellet, and after tempereture of flue gasses raise on value of 55 °C, regulation receives signal that fire is on and stove continues to work with set values. 6.2 Shutting down of stove Press and hold button 4 for 3 (three) seconds.

  • Page 27: Adjustment Of Air Temperature

    Minitherm - ThermoFLUX Regulation on the stove is set in the way to modulate (power goes into lowest one ) it's work when 4 C is reched below set temperature – read 6.5 Modulation 6.4 Adjustment of air temperature Adjustment of air temperature is done by pressing button 1 or 2 (*1).

  • Page 28: Cleaning Of Fire-Pot

    Minitherm - ThermoFLUX If temperature rises above set temperature by 3 °C, stove will be shut down automatically and on display will be written WAIT COOLING. When temperature in the stove decreases for 2 °C below set temp. regulation will start process of ignition again.

  • Page 29: Cleaning And Maintenance

    Minitherm - ThermoFLUX Cleaning and maintenance To secure proper work of the stove, cleaning and maintenance is neccesary. 7.1 Daily cleaning   Turn the stove off and wait until it has been cooled.  Open the stove door. ...

  • Page 30: Cleaning The Tube Heat Exchanger

    Minitherm - ThermoFLUX  Using the vacuum cleaner take the ash out of the stove into a fire- resistant container.  Put the ash pan back into the firebox.  Close the door before ignition 7.3 Cleaning the tube heat exchanger...

  • Page 31: Cleaning The Flue Gas Chamber

    Minitherm - ThermoFLUX 7.4 Cleaning the flue gas chamber  Remove 4 pieces hexagonal nuts on top  Remove side panels...
  • Page 32 Minitherm - ThermoFLUX  Open cover on flue gas chamber  Clean the sediments out of the tube heat exchanger using the vacuum cleaner. Check if there is any ash left in the firebox or in the ash pan and clean them in accordance with the instructions given in paragraphs which refer to cleaning the firebox.

  • Page 33: Connection Options

    Minitherm - ThermoFLUX Connection options 8.1 Scheme for electric connection On the back side of the silo there is connection box for :  Power 220 V, 50 Hz  Room thermostat Stove needs to be connected to el. Power supply 220 V and 50 Hz, through fuse of 6 –...

  • Page 34: Alarms

    Minitherm - ThermoFLUX Alarms If faults occur in the heating system, it is possible to fix some of them by following these instructions. Display Description Solution Cancel the alarm can be executed Alarm active- by pressing the button 4 After that, the display lists FINAL indicated next to the sign CLEANING lasting 4 minutes.
  • Page 35 Minitherm - ThermoFLUX Excessive amounts of feed pellets. Call service Wait for the stove to cool down and then unscrew the plastic cap and suitable tool to reset the switch. Safety thermostat (STB) has been activated because SAFETY THERMAL the stove air temperature...

  • Page 36: Instruction About Safety Removal And Proper Disposal Of Stove

    Minitherm - ThermoFLUX Instruction about safety removal and proper disposal of stove 10.1 Disposal Following elements are made of metal and can be disposed on landfills for metal:  stove  cover metal sheets  feeding system (except motor) ...

  • Page 37: Guarantee

    11.2 Guarantee terms First start up of the stove needs to be done by authorised service, or person authorised by ThermoFLUX or authorised importer – distributor. Stove must work in accordance with terms and conditions given in this manual. Stove needs to be instaled in accordance with all state regulations and law terms.

  • Page 38: Technical Personal

    Minitherm - ThermoFLUX Technical personal List of technical personal and authorised distributers you can find on our web pages : www.thermoflux.ba www.servis.thermoflux.ba...

  • Page 39: Eu Label

    Minitherm - ThermoFLUX EU Label...
  • Page 40 Minitherm - ThermoFLUX...
  • Page 41 Minitherm - ThermoFLUX...
  • Page 42 Minitherm - ThermoFLUX ThermoFLUX d.o.o. Bage br.3, Jajce Bosnia and Herzegovina Tel/fax +387-30-657-100 www.thermoflux.ba User manual MINITHERM - – LCD EN...
