- Page 1 INSTALLATION INSTRUCTIONS Wall-Mounted Basin Mixer & Two-Handle Valve Applicable Product Number: 6777-9H-81CP 6777-92-81CP 6777-9H-82CP www.justime.com 040917 MADE IN TAIWAN...
-
Page 2: Care And Cleaning
CARE & CLEANING CAUTION : This product might be damaged by improper installation, acid cleaning solution, misuse, improper care and cleaning. 1. Always follow the INSTALLATION INSTRUCTIONS provided and use extreme care while installing. 2. Do not use acid cleaning solution or abrasive cleaner (Ex: Hydrochloric acid or toothpaste);... - Page 3 FIXING CONTENTS A. Valve Body X 1 (with sleeve) B. Base of Handle × 2 C. Handle × 1 (with Packing) (with Red Mark) D. Handle × 1 (with Blue Mark)
- Page 4 FIXING CONTENTS FIXING CONTENTS For 6777-92-81CP E. Connector X 1 F. Nipple X 2 (with Gasket) G. Flange X 1 H. Spout X 1 (with O-Ring) I. Hex. Key (2.5mm) X 1 J. Key for Aerator X 1...
-
Page 5: Installation Note
INSTALLATION NOTE ! CAUTION : Please read the following point carefully before Installation. 1. Keep the Valve Body is horizontal and parallel to the wall that will be finished. 2. Connect hot and cold supply pipes to the Valve Body , and keep the distance between 2”... - Page 6 Finished Wall 2"(5cm)MIN 3"(7.6cm)MAX Water Supplies...
-
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS A. Valve Body Sleeve Cover hot water supply cold water supply * Use Sleeves to protect the cartridge and thread before installation, and Sleeves could be removed only after complete the finished wall. * Remove the Covers of cold and hot inlets before installation. * Install hot and cold water supply pipes as figure shows. - Page 8 Finished Wall Finished Wall 2"(5cm)MIN 0.4"(1.1cm)MIN 3"(7.6cm)MAX 1.5"(3.7cm)MAX Water Supplies * Connect hot and cold supply pipes to the Valve Body , and keep the distance between 2” (5cm) minimum and 3” (7.6cm) maximum from the Finished Wall to the center of Valve Body ; or keep the distance be 0.4 “...
- Page 9 Installation Steps For 6777-92-81CP Finished Wall Distance from Finished Wall Nipple (Long) Nipple (Short) 0.3"(0.8cm)~0.7"(1.9cm) 0.7"(1.9cm)~1.3"(3.4cm) Available distance for different Nipple * Available distance from Finished Wall for Nipple (Long) is 0.3"(0.8cm)~0.7"(1.9cm); for Nipple (Short) is 0.7"(1.9cm)~1.3"(3.4cm).
- Page 10 Choose the proper Nipple by the depth of Valve Body. F. Nipple E. Connector with Gasket * Choose proper Nipple , apply the pipe compound or thread sealant tape and then screw it to the Valve Body . Screw and tighten Connector with Gasket to the Nipple .
- Page 11 Finished Wall Distance From Finished Wall Nipple (Short) Nipple (Long) 0.8"(2.1cm)~1.4"(3.6cm) 1.4"(3.6cm)~1.8"(4.6cm) Available distance for different Nipple * Available distance from Finished Wall for Nipple (Short) is 0.8"(2.1cm)~1.4"(3.6cm); for Nipple(Long) is 1.4(3.6cm)~1.6"(4.6cm).
- Page 12 I. Hex. Key (3.0mm) Set Screw X2 H. Spout O-Ring G. Flange * Insert the Spout into the Valve Body , confirm the direction of Spout , tighten the set screws of Connector to fix the Spout , and then screw Flange with O-Ring to the Connector .
- Page 13 hot valve close cold valve B. Base of Handle close * Screw the Base of Handle to the shanks of hot and cold valves till against finished wall.
- Page 14 C. Handle × 1 (with Red Mark) D. Handle × 1 (with Blue Mark) * Confirm Hot Valve and Cold Valve have been turned to closed position before install the Handle . Press both hot and cold Handles onto valve spindles until hear the click sound as the figure shows.
- Page 15 Installation Steps For 6777-9H-81CP outlet hot water supply cold water supply * Install hot and cold water supply pipes and outlet.
- Page 16 Installation Steps For 6777-9H-82CP hot water supply outlet cold water supply * Install hot and cold water supply pipes and outlet.
- Page 17 hot valve close cold valve B. Base of Handle close * Screw the Base of Handle to the shanks of hot and cold valves till against finished wall.
- Page 18 C. Handle × 1 (with Red Mark) D. Handle × 1 (with Blue Mark) * Confirm Hot Valve and Cold Valve have been turned to closed position before install the Handle . Press both hot and cold Handles onto valve spindles until hear the click sound as the figure shows.
- Page 19 Finish Installation 6777-92-81CP 6777-9H-81CP 6777-9H-82CP...
- Page 20 Purchase place Address Purchase Date Purchase Price w w w . j u s t i m e . c o m No.99 Sec.3 Chang Tsao Rd. Ho Me, Chang Hua, Taiwan TEL: +886-4-7629971~4 FAX: +886-4-7526980 E-mail: shengtai@ms10.hinet.net Facebook: www.facebook.com/JUSTIME...
