hentech RC03B Manual

RC03B is a single remote control device used to control underwater light within 200m
(actual distance varies by environment)
Important: This manual includes installation and usage information. Please review all
instructions before installing or initiating. For best functionality, please follow
following guideline

Basic Parameter for RC03B

Degree of Protection：IP63
Size：135mm x 135mmx 45mm
Weight：
Input Voltage：220V AC
Output Voltage：Depending on your input voltage
Operating Temperature:
Operating Humidity:
Control Distance： within 200M
Packaging：RC03B Remote Device × 1 Remote Control × 2
Product Diagram：

OPERATION

Operate with a remote emitter
Button operation:
Button 1: switch to the next color program
Button 2: turns the lamps ON/OFF.
Button 3: turns ON/OFF switch A.
Button 4: turns ON/OFF switch B.
RC03B Remote Control Manual
:
0.37KG
- 4 0 º C
1 0 % ～ 9 0 % R H
B
A
color&light
～ + 7 0 º C
Input 220V
Wiring Diagram
1
3
2
4
