- Page 1 Installation Instruction AXIstorage Li SH AXITEC Energy GmbH & Co. KG Otto-Lilienthal-Str.5 DE-71034 Böblingen Tel.: +49 7031 6288-5173 Fax: +49 7031 6288-5187 Web: http://www.axitecsolar.com V 2 0 0 2 1 3 E N S e i t e 1 | 27...
-
Page 2: Table Of Contents
Inhalt Safety ............................4 Important notes on this manual ..................4 1.1.1 Purpose........................4 1.1.2 Target group......................4 1.1.3 Storage ........................4 Symbol explanations .......................5 1.2.1 Explanations regarding safety instructions and warnings ..........5 1.2.2 Explanation of pictograms and symbols..............6 Battery application area ....................7 1.3.1 Appropriate use .......................7 1.3.2 Perilous misuse......................7 Main hazards ........................8... - Page 3 Connecting the inverter ....................20 3.4.1 SMA Sunny Boy Storage 3.7 / 5.0 / 6.0 ..............20 3.4.2 Kostal PLENTICORE plus..................21 Putting the AXIstorage Li SH system into operation ............23 Repair ..........................23 Decommissioning, storage ....................23 Introduction ......................... 23 5.1.1 Safety regulations ....................
-
Page 4: Safety
Energypack. Important notes on this manual 1.1.1 Purpose This document describes the installation of an AXIstorage Li SH battery system in combination with SMA Sunny Boy Storage 3.7/5.0/6.0 or Kostal PLENTICORE plus. 1.1.2 Target group The installation instructions are intended exclusively for qualified electricians. -
Page 5: Symbol Explanations
Symbol explanations 1.2.1 Explanations regarding safety instructions and warnings Safety Instructions are universally valid and can be found in a safety chapter or at the beginning of a chapter. Warnings are placed directly before behavioral guidelines. They help you to avoid dangers during an upcoming operation. -
Page 6: Explanation Of Pictograms And Symbols
1.2.2 Explanation of pictograms and symbols Symbols Declarationg General warning sign. Note additional information. Warning of electrical voltage. Warning of dangers from batteries that are being charged. Warning of flammable substances. Hot surface warning. Warning of hand injuries. No access for persons who have pacemakers or implanted defibrillators. Manual lifting prohibited. -
Page 7: Battery Application Area
1.3.1 Appropriate use The AXIstorage Li SH is a battery system. It serves as an energy storage device within an electricity storage system for private households and small businesses. It enables you to temporarily store self - produced electricity, e.g. from photovoltaic - or CHP (cogeneration of heat and power) plants. The electricity can later be used when needed. -
Page 8: Main Hazards
Fire Qualification of the users Only the electricians qualified by the Axitec Energy or the Axitec Energy itself may work with the battery system. Do not leave the children unattended or allow them to be near the battery system. -
Page 9: Personal Protective Equipment (Ppe)
Personal protective equipment (PPE) Use foot protection and hand protection during assembly. Emergency instructions 1.7.1 Measures in case of fire Do not inhale smoke and vapors. Report a lithium-ion fire to the fire department. If possible: Close the doors. ... -
Page 10: Product Description
2 Product description Important information about the product Overall view Figure 1 Overa l l vi ew of battery s ystem. 2.1.1 Conformity The following standards, laws and guidelines were taken into account during the development of the Energypack: EU directive with CE labelling obligation ... -
Page 11: Scope Of Delivery
2.2 Scope of delivery AXIstorage Li SH system housing Installation kit (in system housing) is included: 6 RJ45 patch cables 1 RJ45 Terminator 12 screws M6x10 3 Dummy sockets, power plugs 2 PG connections ... -
Page 12: Technical Data
SMA Sunny Boy Storage 3.7 / 5.0 / 6.0 (CAN) KOSTAL PLENTICORE plus (RS-485) 2.3.4 Supply, interfaces, connections The AXIstorage Li SH is supplied with the following connections: + DC cable: AWG8 red (American standard for wire cross section) - DC cable: AWG8 black ... -
Page 13: Ambient Conditions
The Energypack has one socket which contains (+) and (-) as power contacts and two RJ45 sockets which contain CAN bus and status and signal lines: 1 socket with power contacts (+) and (-) 1 RJ45 sockets with CAN bus connection for monitoring and control of the Energypack by the higher-level controller ... -
Page 14: Commissioning
The inverter should be mounted at least 20 cm above the battery system. At a distance of up to 30 cm, the cables already attached to the AXIstorage Li SH can be used. Leave space of at least 30 cm free to the left and right of the battery system to get to the DC disconnect switch to ensure sufficient air circulation. -
Page 15: Mounting
Screws M5 (SW4) Position the base of the battery housing at the intended installation location (and screw it on if necessary). 3.3 Assembly 3.3.1 Installing AXIstorage Li SH - Energypack einbauen Safety Instructions CAUTION Risk of crushing due to improper installation. - Page 16 Perform a visual inspection. Clean the contact points with a dry cloth if necessary. The Energypack may only be inserted into the AXIstorage Li SH battery system provided for this purpose. The power storage system is securely installed.
- Page 17 To ensure the best possible cooling, we recommend that the Energypack are inserted as follows: Figure 2: Ins ert 3 to 6 Energypack with with 3 Energypack 4 Energypack with with 5 Energypack 6 Energypack Screw the downholder to the right and left of the base of the system housing. Screw each Energypack with two screws (M6) to the downholder/grounding support.
-
Page 18: Connect Energypack Next To Each Other In Series
Use the patch cables to connect the BMS master (left of the two RJ45 sockets) with the installed Energypack. For example, refer to Figure 4 Figure 4: Connect the Energypack to the BMS master using the patch cables Plug the terminator into X2 of the last Energypack. 3.3.2 Connect Energypack next to each other in series WARNING Electric shock from live parts. -
Page 19: Closing The Housing Of The Battery System
Remove the safety cover of the "Power" sockets. Insert the power plug for the respective Energypack until it clicks into place. For example, refer to Figure 5. Figure 5: Power pa th with s witching devi ces a nd BMS Check by pulling the power plugs to make sure that the latching is engaged. -
Page 20: Disposal Measures
PG screw glands into the connection compartment of the inverter. Figure 6: Connecting the SMA SB Storage to the AXIstorage Li SH Connect the cables in the inverter according to the Sunny Boy Storage 3.7 / 5.0 / 6.0 operating instructions. -
Page 21: Kostal Plenticore Plus
Close the housing of the inverter. 3.4.2 Kostal PLENTICORE plus In order to operate the AXIstorage Li SH system communicatively with the Kostal PLENTICORE plus, the communication must be switched to RS485. Disconnect the X2 plug from the BMS master (green plug at top left) ... - Page 22 Connect the cables in/on the inverter according to the PLENTICORE plus operating instructions. Connecting battery communication cable: white: RS485B yellow: RS485A black: GND 0V red: wake-up_Bat Figure 8: Connection of the PLENTICORE plus - communication cable Shut the inverter down Establish DC connection: ...
-
Page 23: Putting The Axistorage Li Sh System Into Operation
5.1.1 Safety regulations Switch off the DC switch on the left side of the AXIstorage Li SH battery system. Open the AXIstorage Li SH and unlock and disconnect both the patch cables and the power cables on the Energypack Energypack. -
Page 24: Storage Connections
5.2 Storage connections 5.2.1 Storage period Do not store the module for more than six months from the date of manufacture (see type label). The module must be recharged for longer storage periods. 5.2.2 Physikcal conditions Store the module in a dry place, protected from solar radiation, maximum 2000 m above sea level. The following conditions should prevail on an average: ... -
Page 25: Disposal
7 Disposal Batteries may not be disposed of in household garbage. As a consumer, you are legally obligated to return used batteries. The return is free of charge. If lithium batteries are not disposed of properly, fire or leakage of hazardous substances may cause damage to health and the environment. -
Page 26: Further Directories
Figure 4: Connect the Energypack to the BMS master using the patch cables ........18 Figure 5: Power path with switching devices and BMS ..............19 Figure 6: Connecting the SMA SB Storage to the AXIstorage Li SH ........... 20 Figure 7: Connecting the PLENTICORE plus to the AXIstorage Li SH ..........21 Figure 8: Connecting the PLENTICORE –... -
Page 27: Addresses, Identification And Notes
Otto-Lilienthal-Straße 5 71034 Böblingen Germany Tel.: +49 (0) 7031 6288-5186 energy@axitecsolar.com Product- AXIstorage Li SH (system housing), Item no. AY10469 identification Energypack (modular battery), Item no. AY10468 Country of Origin: Germany Symbol: CE Document- Original installation instructions AXIstorage Li SH identification Version: V200205EN (based 1.01)
