Skycoin Skywire Miner Assembly Manual

Hide thumbs Also See for Skywire Miner:

Advertisement

Quick Links

Download this manual
Skywire Miner
Assembly
Manual
Contact
Address
#1101�South Tower,
No.1839 Qixin Road,
Minhang, Shanghai, P.R.C
Website
www.skycoin.net
Email
support@skycoin.net

Advertisement

loading
Need help?

Need help?

Do you have a question about the Skywire Miner and is the answer not in the manual?

Questions and answers

Related Manuals for Skycoin Skywire Miner

Summary of Contents for Skycoin Skywire Miner

  • Page 1 Skywire Miner Assembly Manual Contact Address Website Email #1101�South Tower, www.skycoin.net support@skycoin.net No.1839 Qixin Road, Minhang, Shanghai, P.R.C...

  • Page 2: Table Of Contents

    CONTENTS ASSEMBLY MANUAL FOREWORD SCREWS & PARTS FRAME ASSEMBLY ELECTRONIC ASSEMBLY FINAL ASSEMBLY CABLE CONNECTION...
  • Page 3 SKYWIRE MINER OVERVIEW...

  • Page 4: Foreword

    Thank you for your interest and trust in the Skywire Miner. In using the product, you are obliged to install and operate the Skywire Miner according to the safety instructions, warnings, speci�cation sheet, and assembly manual — as well as common sense.
  • Page 5 Firm connections — Before powering up the Skywire Miner, ensure that all connections are secure for all components, and con�rm that there are no loose screws or loose components anywhere within the Skywire Miner unit. Do not connect any devices to the Skywire Miner that are not included in this package.
  • Page 6 When the power is on, do not contact any conductive objects with any Skywire Miner components. • Do not touch the Skywire Miner with any wet part of your body, and do not operate the Skywire Miner while barefoot. •...
  • Page 7 FOREWORD SPECIFICATION Speci�cation Sheet of Skywire Miner Build 2.0 Physical Net Weight 4 kg (9 lbs) Chassis Demensions (LxWxH) 235x235x275 mm (9.5x9.5x11 inch) Shipping Weight 4.5kg (10 lbs) Shipping Dimensions (LxWxH) 320x320x190 mm (12.5x12.5x7.5 inch) Structure Materials Aluminum Alloy & Acrylic...

  • Page 8: Screws & Parts

    SCREWS & PARTS SCREWS AND PARTS...

  • Page 9: Frame Assembly

    STEP 01 FRAME ASSEMBLY 1194 Shorter Aluminum Profile 0508 M5x8mm Hex Screw 0502 M5 T-Nut 1028 Corner Bracket...
  • Page 10 STEP 02 FRAME ASSEMBLY 1234 Longer Aluminum Profile 0508 M5x8mm Hex Screw 0502 M5 T-Nut...
  • Page 11 STEP 03 FRAME ASSEMBLY 1234 Longer Aluminum Profile 0508 M5x8mm Hex Screw 0502 M5 T-Nut 1028 Corner Bracket...

  • Page 12: Electronic Assembly

    STEP 04 ELECTRONIC ASSEMBLY 2002 Acrylic Inner Panel 0310 M3x10mm Hex Screw 0320 20mm F-F Spacer Strip the protective film before using acrylic panels.
  • Page 13 STEP 05 ELECTRONIC ASSEMBLY 5011 Power Supply Unit 0310 M3x10mm Hex Screw 0303 M3 Nylon Spacer Switch the power supply unit to proper voltage range before mounting. Mind the direction of power supply unit, connector side down. If some of the screws can’t grab the holes, use 0312 instead.
  • Page 14 STEP 06 ELECTRONIC ASSEMBLY 4100 Orange Pi Prime 0336 30mm F-M Spacer It is suggested to flash and insert Micro SD before mounting the Orange Pi Prime.
  • Page 15 STEP 07 ELECTRONIC ASSEMBLY 2003 Acrylic Outer Panel 4100 Orange Pi Prime 0310 M3x10mm Hex Screw 0326 20mm F-M Spacer...
  • Page 16 STEP 08 ELECTRONIC ASSEMBLY 2001 Acrylic Back Panel 5001 Power Socket 0312 M3x12mm Hex Screw 0302 M3 Nut Ensure the switch is off, and DO NOT plug the power cord.
  • Page 17 STEP 09 ELECTRONIC ASSEMBLY 5020 Power Distribution Board 0303 M3 Nylon Spacer 0312 M3x12mm Hex Screw 0302 M3 Nut 0510 M5x10mm Hex Screw 0502 M5 T-Nut...
  • Page 18 STEP 10 CABLE CONNECTION 7010 DC Cable 7020 AC Cable 7011 DC Cable 7021 AC Cable 7012 DC Cable 7022 Earthing Cable 7013 DC Cable 7024 AC Cable 7014 DC Cable Check the cable codes carefully. Leave the leftmost tab on the power socket UNUSED (in green circle�. Cable 7011, 7012, 7013, 7014 should be crimped onto the PCB with pliers for solid connection.
  • Page 19 STEP 11 ELECTRONIC ASSEMBLY...
  • Page 20 STEP 12 ELECTRONIC ASSEMBLY 0510 M5x10mm Hex Screw 0502 M5 T-Nut...

  • Page 21: Final Assembly

    STEP 13 FINAL ASSEMBLY 0502 M5 T-Nut Put the nuts into the slot for later use.
  • Page 22 STEP 14 FINAL ASSEMBLY...
  • Page 23 STEP 15 FINAL ASSEMBLY 0510 M5x10mm Hex Screw Shake carefully to align the nuts to the holes.
  • Page 24 STEP 16 FINAL ASSEMBLY 3000 Router 0406 M4x6mm Hex Screw 0402 M4 T-Nut...
  • Page 25 STEP 17 FINAL ASSEMBLY 0508 M5x8mm Hex Screw 0502 M5 T-Nut 1028 Corner Bracket This step is based on the structure indicated on page 9.
  • Page 26 STEP 18 FINAL ASSEMBLY Loose and re-tighten all the screws on the vertical pillars, helping release the stress in the structure.
  • Page 27 STEP 19 FINAL ASSEMBLY 0510 M5x10mm Hex Screw...

  • Page 28: Cable Connection

    STEP 20 CABLE CONNECTION 7022 Earthing Cable 7011 DC Cable 7023 Earthing Cable 7012 DC Cable 7033 DC Cable 7020 AC Cable 7021 AC Cable 7012 7011 7022 7021 7020 7023 Check the cable codes carefully.
  • Page 29 STEP 21 CABLE CONNECTION 6020 Ethernet Cable 6025 Ethernet Cable 7033 DC Cable...
  • Page 30 STEP 22 CABLE CONNECTION 7010 DC Cable...
