- Page 1 Skywire Miner Assembly Manual Contact Address Website Email #1101 South Tower, www.skycoin.net support@skycoin.net No.1839 Qixin Road, Minhang, Shanghai, P.R.C...
- Page 2 SKYWIRE MINER OVERVIEW...
-
Page 3: Table Of Contents
CONTENTS ASSEMBLY MANUAL FOREWORD SCREWS AND PARTS FRAME ASSEMBLY ELECTRONIC ASSEMBLY FINAL ASSEMBLY CABLE CONNECTION... -
Page 4: Foreword
Thank you for your interest and trust in the Skywire Miner. In using the product, you are obliged to install and operate the Skywire Miner according to the safety instructions, warnings, specification sheet, and assembly manual — as well as common sense. - Page 5 Skywire Miner unit. Do not connect any devices to the Sky- wire Miner that are not included in this package.
- Page 6 When the power is on, do not contact any conductive objects with any Skywire Miner components. • Do not touch the Skywire Miner with any wet part of your body, and do not oper- ate the Skywire Miner while barefoot. •...
- Page 7 FOREWORD SPECIFICATION Specification Sheet of Skywire Miner Build 2.0 Physical Net Weight 4 kg (9 lbs) Chassis Demensions (LxWxH) 235x235x275 mm (9.5x9.5x11 inch) Shipping Weight 4.5kg (10 lbs) Shipping Dimensions (LxWxH) 320x320x190 mm (12.5x12.5x7.5 inch) Structure Materials Aluminum Alloy & Acrylic...
-
Page 8: Screws And Parts
SCREWS & PARTS SCREWS AND PARTS... -
Page 9: Frame Assembly
STEP 01 FRAME ASSEMBLY 1194 Shorter Aluminum Profile 0508 M5x8mm Hex Screw 0502 M5 T-Nut 1028 Corner Bracket... - Page 10 STEP 02 FRAME ASSEMBLY 1234 Longer Aluminum Profile 0508 M5x8mm Hex Screw 0502 M5 T-Nut...
- Page 11 STEP 03 FRAME ASSEMBLY 1234 Longer Aluminum Profile 0508 M5x8mm Hex Screw 0502 M5 T-Nut 1028 Corner Bracket...
-
Page 12: Electronic Assembly
STEP 04 ELECTRONIC ASSEMBLY 2002 Acrylic Inner Plate 5mm 0310 M3x10mm Hex Screw 0320 20mm F-F Spacer... - Page 13 STEP 05 ELECTRONIC ASSEMBLY 5011 Power Supply Unit 0310 M3x10mm Hex Screw 0303 M3 Nylon Spacer...
- Page 14 STEP 06 ELECTRONIC ASSEMBLY 4100 Orange Pi Prime 0336 30mm F-M Spacer...
- Page 15 STEP 07 ELECTRONIC ASSEMBLY 2003 Acrylic Outer Plate 5mm 4100 Orange Pi Prime 0310 M3x10mm Hex Screw 0326 20mm F-M Spacer...
- Page 16 STEP 08 ELECTRONIC ASSEMBLY 2001 Acrylic Back Plate 5mm 5001 Power Socket 0312 M3x12mm Hex Screw 0302 M3 Nut...
- Page 17 STEP 09 ELECTRONIC ASSEMBLY 5020 Power Distribution Board 0303 M3 Nylon Spacer 0312 M3x12mm Hex Screw 0302 M3 Nut 0510 M5x10mm Hex Screw 0502 M5 T-Nut...
- Page 18 STEP 10 CABLE CONNECTION 7010 Cable 7020 Cable 7011 Cable 7021 Cable 7012 Cable 7022 Cable 7013 Cable 7024 Cable 7014 Cable...
- Page 19 STEP 11 ELECTRONIC ASSEMBLY...
- Page 20 STEP 12 ELECTRONIC ASSEMBLY 0510 M5x10mm Hex Screw 0502 M5 T-Nut...
-
Page 21: Final Assembly
STEP 13 FINAL ASSEMBLY 0502 M5 T-Nut... - Page 22 STEP 14 FINAL ASSEMBLY...
- Page 23 STEP 15 FINAL ASSEMBLY 0510 M5x10mm Hex Screw...
- Page 24 STEP 16 FINAL ASSEMBLY 3000 Router 0406 M4x6mm Hex Screw 0402 M4 T-Nut...
- Page 25 STEP 17 FINAL ASSEMBLY 0508 M5x8mm Hex Screw 0502 M5 T-Nut 1028 Corner Bracket...
- Page 26 STEP 18 FINAL ASSEMBLY...
- Page 27 STEP 19 FINAL ASSEMBLY 0510 M5x10mm Hex Screw...
-
Page 28: Cable Connection
STEP 20 CABLE CONNECTION 7011 Cable 7022 Cable 7012 Cable 7023 Cable 7020 Cable 7033 Cable 7021 Cable 7012 7011 7022 7021 7020 7023... - Page 29 STEP 21 CABLE CONNECTION 6020 Cable 6025 Cable 7033 Cable...
- Page 30 STEP 22 CABLE CONNECTION 7010 Cable...
