QK‐AMBANT is a trigger antenna that allows activating a transmitting tag when this one enters the detection range of
the antenna. QK‐AMBANT is equipped with a contact for presence detectors like photocells and loop detectors.


1. TECHNICAL CHARACTERISTICS

Operating frequency

Power supply

Consumption
Radiated power

Wiring
Operating temperature
Protection rate
Dimension
Enabling area (hands‐free mode)

Maximum detection speed




www.quikoitaly.com

QK‐AMBANT



4 wires (section 0,5mm2)
QK‐AMBANT
125kHz

230Vac +/‐ 10%

<50mA

<25mW


‐20°C / +55°C

IP66

350x310x40mm

5m

50km/h



Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QK-AMBANT and is the answer not in the manual?

Questions and answers

Summary of Contents for quiko QK-AMBANT

  • Page 1 QK‐AMBANT                        QK‐AMBANT is a trigger antenna that allows activating a transmitting tag when this one enters the detection range of  the antenna. QK‐AMBANT is equipped with a contact for presence detectors like photocells and loop detectors.      1. TECHNICAL CHARACTERISTICS     QK‐AMBANT  Operating frequency  125kHz      Power supply  230Vac +/‐ 10%      Consumption  <50mA    Radiated power  <25mW      Wiring  4 wires (section 0,5mm2)    Operating temperature  ‐20°C / +55°C   ...
  • Page 2 2. CONNECTION                      Connect the power supply wire to the 230Vac and connect the 4 signal wires as follows:     Signal  Cable colour   Presence + (12 V)  Red      ‐(GND)   Black      Sync IN   Green    Sync OUT   White        If the presence detection signal (red) is not used, please join it to the black wire (GND), and the device will always  detect presence.  In case of using more than one trigger antenna in series (maximum 4), connect the synchronism signal OUT to the  synchronism signal IN of the following activator, to avoid interference between them. See connection diagram above.   If you want to connect only one antenna join the two synchronism signals IN and OUT.       ...
  • Page 3 3. INSTALLATION   1. Equipment  2. Adhesive label  3. Wall fixing holes  4. Configuration pushbutton  5. Led  6. Mounting bracket            3.1. WALL INSTALLATION                                 www.quikoitaly.com     ...
  • Page 4 3.2. INSTALLATION WITH BRACKET                              4. CONFIGURATION OF CHANNELS AND GROUPS     Use the button (4) to configure the operating mode of the antenna  Channel configuration: Keep the configuration button pressed down until the number of long red signals is  equal to the channel to be configured.  For example, if you want to configure channel 2, release the button  after the second long red signal.   Channel configuration allows selecting the channel to be sent to the radioreceiver by the transmitting tag.    Group configuration: Press the configuration button and keep it pressed down.  The led will issue the red  channel configuration signals followed by a series of flashing green signals to indicate that it will start the  group selection sequence (long green signals indicating groups 1 to 7).  Release the button at the required  group.  For example, if you want to configure group 5, release the button after the fifth long green signal.  Group configuration allows to control separately up to 28 different doors.  The procedure can be carried out as many times as required.        www.quikoitaly.com     ...
  • Page 5 EXAMPLE: Channel 2 Configuration     Operating mode                                             = green    Press button to select channel                                                                                         = red                                                                  Channel 1 Channel 2 Channel 3 Channel 4                                                                                  Release button   EXAMPLE: Group 5 Configuration     Operating mode                                             = green    Press button to select channel                                                                                         = red                                                                  Channel 1 Channel 2 Channel 3 Channel 4                                                                                  Release button     Keep button pressed down to                                  = Flashing green  select group                                                             Group open                                                                                                                                                                       = green                                                      Group 1 Group 2 Group 3 Group 4 Group 5 Group 6 Group 7                                                                                                                    Release button     www.quikoitaly.com     ...
  • Page 6   5. OPERATING        Once the equipment is supplied with electricity, the LED will flash for 3 times.  By bringing the tag/transmitter close to the trigger antenna or pressing the button, the tag/transmitter will  send a signal to the receiver in which it is programmed.      QUIKO  ITALY  declares  that  the  product  QK‐AMBANT  complies  with  the  requirements  of  the  1999/5/EEC  Radio Equipment and Telecommunication Terminal Equipment Directive, provided it is used as established.       DECLARATION OF CONFORMITY :         QUIKO ITALY    Via Seccalegno 19    36040 Sossano (Vi) Italy    Tel + 39 0444 785513   ...
