- Page 1 Air-Powered Right Angle Die Grinder 058-9367-8 Model no. IMPORTANT: INSTRUCTION Please read this manual carefully before MANUAL using this product, and save it for reference.
- Page 2 TABLE OF CONTENTS TECHNICAL SPECIFICATIONS SAFETY GUIDELINES KEY PARTS DIAGRAM TECHNICAL INFORMATION OPERATING INSTRUCTIONS MAINTENANCE TROUBLESHOOTING EXPLODED VIEW PARTS LIST WARRANTY NOTE: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-888-670-6682.
- Page 3 058-9367-8 | contact us 1-888-670-6682 TECHNICAL SPECIFICATIONS This manual contains information that relates to PROTECTING PERSONAL SAFETY and PREVENTING EQUIPMENT PROBLEMS. It is very important COLLET 1/4" (6.4 mm) to read this manual carefully and understand it thoroughly before using the product.
- Page 4 058-9367-8 | contact us 1-888-670-6682 Risk of personal injury. Do not direct compressed air from the • Do not use oxygen or any other combustible or bottled gas to air hose toward the user or other persons. power air-powered tools. Failure to observe this warning can cause explosion and serious personal injury or death.
- Page 5 058-9367-8 | contact us 1-888-670-6682 • Do not wear watches, rings, bracelets, or loose clothing when using Disconnect the tool from the air supply and turn off any air tool. the compressor before changing accessories, before • Keep proper footing at all times in order to ensure correct balance.
- Page 6 Be sure to use a proper air compressor with MAXIMUM air-powered tools. ® The compressor should be able to supply a minimal air delivery of 2.2 CFM @ 90 PSI to ensure the compressor can run continuously with the MAXIMUM ® Air-powered Right Angle Die Grinder. Air Compressor...
- Page 7 • Maintain the air pressure at 90 PSI and air flow according to the recommended specifications. Do not exceed the maximum or minimum • Always use clean, dry, regulated, compressed air at the recommended pressures. Operating the tool at inappropriate pressure (too low or too pressure (see section “Technical Specifications”).
- Page 8 058-9367-8 | contact us 1-888-670-6682 LOADING AND OPERATION 3. Plug in compressor, turn it on to set the Fig. A Fig. C pressure regulator to 90 PSI, attach one end 1. Disconnect the tool (1) from the air hose of the air hose to the compressor and the other (2) (Fig.
- Page 9 058-9367-8 | contact us 1-888-670-6682 • Lubrication: If the Air-powered Right Angle MAXIMUM SERVICE INTERVAL TOOLS OR Die Grinder and compressor are not equipped MAINTENANCE DESCRIPTION MATERIALS Each use or with an in-line lubrication system, place up REQUIRED...
- Page 10 058-9367-8 | contact us 1-888-670-6682 Troubleshooting PROBLEM POSSIBLE CAUSES SOLUTIONS The following chart lists common issues and solutions. Please read it Tool runs 1. Motor parts are 1. Check filter and air inlet for blockage. carefully and follow all instructions closely.
- Page 11 058-9367-8 | contact us 1-888-670-6682 Description Description Housing Cylinder Pin seat Rotor sleeve Trigger Front cover Trigger pin Bearing 608zz Torsion spring Gear wheel Trigger ring Clamp nut Pin 3 x 18 Hex nut Pin 3 x 24 Elbow assembly O-ring 3.3 x 1.5...
- Page 12 058-9372-4 | contact us 1-888-670-6682 model no. 058-9367-8 | contact us 1-888-670-6682 This MAXIMUM product is guaranteed for a period of 5 years This warranty will not apply to any parts other than original parts, from the date of original retail purchase against defects in...
- Page 13 Maximum Canada will maintain this product and replace critical parts Neither the retailer, Maximum Canada, nor the manufacturer shall be liable for which have worn beyond reasonable use through normal use of such any other expense, loss or damage, including, without limitation, any indirect, product, any time during the first year after purchase.
