LCD panel

After the Digital Ink Pad+ is turned on, you can see the following icons displayed on
the LCD panel:
(a) Folder (A ~ Z).
(b) Page number (1 ~ 999).
(c) Current page contains contents. Current page is blank.
(d) Appears when writing with the digital ink pen.
(e) Icons displayed when hovering over the Ink Pad control buttons.
(f) Battery life indicator. Blank indicates no power. Flashing indicates low power.
(g) Memory storage indicator. Blank indicates no data.
(h) M: using internal memory; SD: using a SD card.
(i) Microphone recording displays the filename. This changes to when an MP3
file is being played.
Page | 6
