Installing a nd r emoving t he B attery P ack:
1. Push t he B attery P ack a ll t he w ay i n
until t he l atch c licks
2. To r emove t he B attery P ack, s queeze
the B attery P ack e ject r elease
latches o n e ither s ide o f o pening t o
partially e ject t he B attery P ack, t hen
pull t he B attery P ack o ut
Maintenance -­‐ Power
Defibtech, L LC | 7 41 B oston P ost R oad, G uilford, C T 0 6437 | w ww.defibtech.com
Charging t he B attery P ack
with t he A C A dapter:
1. Install t he B attery P ack
into the C ompression M odule
2. Connect t he k eyed A C
Adapter P lug t o t he e xternal
power i nput j ack o n t he
Compression M odule b eing
sure t o a lign w ith t he n otch
on t he j ack s o t hat i t w ill l ock
into p lace
3. To r emove t he p lug,
grasp t he t op-­‐most
portion o f t he p lug
barrel a nd p ull
