- Page 1 ONYX-W Wall Mount Instructions 2015...
- Page 2 General Installation Overview Mounting: The Onyx-W includes a steel bracket that is designed to be bolted to a wall and then the machine is placed onto the bracket, supported along the top edge and then fastened by screws through the inside of the Onyx-W.
- Page 3 Installing the Wall Mount The installation kit includes the following hardware: 12 Heavy Duty Wall Anchors (Bolts / Washers / Expanding Nuts) 8 Screws (ATM to Wall Mount) Tools: If using the anchors supplied with the kit, you’ll need to drill 12 holes that are 5/8”...
- Page 4 Use the wall mount bracket as a template and mark holes for drilling. The mount uses elongated holes across the top, middle and bottom edges of the mounting plate for the anchor bolts. The elongated mounting holes provide flexibility to position the bracket.
- Page 5 If you are going to route the cables internally through the wall, then you can cut out a section of the wall at this point in the mounting bracket. See red circle above.
- Page 6 Make sure the door latch is closed before lifting the machine in place. The slot in the back of the Onyx-W fits over the tab at the top of the mounting bracket. This will allow it to hang in place.
- Page 7 With the machine installed on the mounting bracket, you can now open the front of the machine to access the 8 screws that will be used to secure the machine to the bracket. Open the front door and then rotate the printer assembly out of the way with the green lever.
- Page 8 Once the machine is attached to the mounting plate you can close the vault and printer. If you are running your power and communication cables out the bottom of the chassis, you should now remove the plastic bung from the bottom (behind the printer).
