MAIN CHARACTERISTICS

LED display.
Easy use interface (3 keys).
3 Inputs for temperature sensors (PT1000 type)
1 output for main pump.
1 Extra output (to control additional heat, cooling system...)
Automatic, Off or Manual test mode.
Sensors Auto checks (Short circuit and breaks)
Collector type choice (Tube or panel)
Collector protection (Freeze and over heat)
Permanent memory storage

TECHNICAL CHARACTERISTICS

Operating temperature
Electrical Protection
Installation Category
Pollution Degree
Fusible
Power supply
Outputs:
P1 (Main pump):
P2 (Extra, Additional heat,
cooling...)
Inputs:
T1 (Collector1):
T2 (Tank1):
T3 (Extra sensor):
Software version
0°C – 50°C
IP20
II
2
4AT 230Vac (5x20mm)
230Vac +/- 10% 50Hz
Relay 2A 230VAC
Relay 2A 230VAC
PT 1000 type
PT 1000 type
PT 1000 type
Displayed during the init
Version x.xx
