To the Installer:
Please attach these instructions
next to the water heater.
Installation and Operation Instructions Manual
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause serious
injury or property damage. Refer to this
manual. For assistance or additional
information, consult a qualified installer or
service agency.
CAUTION
The recommended water temperature for
normal residential use is 120°F/49°F. Outlet
water temperatures may exceed the thermostat
setting. Measure water temperature at the tap
nearest to the water heater.
WARNING
Hotter water increases the risk of scald injury.
Before adjusting the water temperature setting,
read this instruction manual. Temperatures at
which injury occurs vary with the person's age
and the length of exposure.
The slower reaction time of children, elderly,
and physically or mentally challenged persons
increases the scalding hazard to them. It is
recommended that lower water temperatures
be used where these exposure hazards exist.
Such households may require a temperature
setting less than 120°F to prevent accidental
contact with hot water.
To lower water temperature use point-of-use
temperature limiting devices.
WARNING
Water heater blankets are not recommended
and will void the warranty.
CAUTION
This water heater is not intended for space
heating applications.
#23580
To the Consumer:
Commercial Electric Water Heater
Models: LCE6, LCE12, LCE20, LCE30, LCE40, LCE50
Warranty, Registration Card and Parts List are included.
Owner: Please remember to return the Registration Card!
Please read these and all component
instructions and keep for future reference.
THIS MANUAL HAS BEEN PREPARED
TO ACQUAINT YOU WITH THE INSTALLATION,
OPERATION, AND MAINTENANCE OF
YOUR WATER HEATER AND TO PROVIDE
IMPORTANT SAFETY INFORMATION.
INSTALLER RESPONSIBILITIES
Please read all instructions thoroughly before
installing or placing the heater into service.
This unit must be installed by licensed or
authorized installers, or technical personnel
that service water heating equipment. The
heater must be installed in accordance with all
local codes and ordinances.
FAILURE TO FOLLOW THESE INSTRUCTIONS
OR ALL APPLICABLE BUILDING CODES AND
REGULATIONS VOIDS THE WARRANTY
ON THIS WATER HEATER.
Local plumbing and electrical codes must
be followed in the installation of this water
heater. In the absence of a local code use the
UNIFORM PLUMBING CODE and the National
Electric Code, NFPA 70, or the Canadian
Electrical Code CSA C22.1. Local codes may
supersede instructions in this installation
manual.
These instructions are a guide for the
correct installation of the water heater.
The manufacturer will not be liable for
damages caused by failure to comply with
the installation and operating instructions
outlined on the following pages.
HANDLING
Before uncrating, check for shipping damage.
Report any damage to your carrier. Note damage
on bill of lading or delivery receipt and file a
claim.
Rev3 10/19
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BOCK LCE6
Summary of Contents for BOCK LCE6
- Page 1 Installation and Operation Instructions Manual Commercial Electric Water Heater Models: LCE6, LCE12, LCE20, LCE30, LCE40, LCE50 Warranty, Registration Card and Parts List are included. Owner: Please remember to return the Registration Card! WARNING...
- Page 2 Page 2...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Section I: Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Section II: General Information . -
Page 4: Section I: Specifications
Number of Capacity Model Elements gallons liters inches mm inches mm inches mm inches mm inches mm LCE6-1 16.00 406 16.50 419 11.25 286 3.50 LCE12-1 20.00 508 16.44 418 10.75 273 2.75 LCE20-1 22.00 559 23.00 584 17.25 438 2.75... - Page 5 SECTION I: SPECIFICATIONS (cont .) Table 2: Recovery Capacities Table 3: Recovery Capacities Upper/Lower Recovery (GPH & LPH) at Temperature Rise (°F & °C) Maximum Element 100 110 120 130 140 °F Input (kW) °C 22.2 27.8 33.3 38.9 44.4 50.0 55.6 61.1 66.7 72.2 77.8 Wattage (kW) Non-Simultaneous 1.5/1.5...
-
Page 6: Section Ii: General Information
(135°F - 181°F) and fixed high limits (200°F). Both thermostats are factory set to 135°F. CAUTION: Hot water in excess of 120°F can cause scalding! Bock recommends a thermostatic mixing valve be installed and used according to the manufacturer’s directions to prevent scalding. Many state and local codes now require installation of these devices. - Page 7 SECTION II: GENERAL INFORMATION ANODE RODS The anode rod is used as a sacrificial element within the volume of the storage tank. The purpose of the magnesium anode rod is to protect the inside of the tank against corrosion. Anode rods should be inspected twice in the first year and at least yearly once a time interval for inspection has been developed.
-
Page 8: Section Iii: Pre-Installation
SECTION III: PRE-INSTALLATION LOCATION CAUTION This water heater must be located in an area where leakage of the tank, water line connections, or the temperature and pressure relief valve will not result in damage to the area adjacent to the water heater or to lower floors of the structure. When such location cannot be avoided, a suitable drain pan must be installed under the water heater. -
Page 9: Section Iv: Installation
SECTION IV: INSTALLATION WATER CONNECTIONS CAUTION This water heater incorporates fittings that contain a nonmetallic lining. DO NOT apply heat to these fittings when making sweat connections to the heater. Sweat tubing to an adapter before securing adapter to any fittings on water heaters. ALL PIPING SHOULD CONFORM TO LOCAL CODES AND ORDINANCES. - Page 10 SECTION IV: INSTALLATION (cont .) PIPING DIAGRAMS Piping connections for single and dual element models are shown in Figures 3 and 4. Figure 3: Piping Connections on Single Element Models Figure 4: Piping Connections on Dual Element Models Page 10...
- Page 11 See Figure 5 for factory wiring diagrams. Conversion of elements or alternative wiring for conversion of phase and/or element operation must be done with the appropriate factory supplied conversion kit. Contact Bock Water Heaters for ordering information. GROUNDING INSTRUCTIONS Single element models have a green screw (ground) located in the junction box for proper connection to ground from the branch circuit.
- Page 12 SECTION IV: INSTALLATION (cont .) Table 7: National Electric Code - Branch Circuit Sizing Table 6: National Electric Code - Branch Circuit Sizing Recommended Copper Wire Size (AWG) Overcurrent Protection Total Water per NFPA 70 Table (fuse or circuit breaker Heater Input Phase 310.15(B)(16)* at 75°C...
- Page 13 SECTION IV: INSTALLATION (cont .) Figure 5: Wiring Diagrams Page 13...
-
Page 14: Section V: Operation
SECTION V: OPERATION CAUTION THE WATER HEATER MUST BE FILLED WITH WATER BEFORE CONNECTING ELECTRIC POWER. When the branch circuit disconnect switch is closed and electric power is applied to the water heater, the operation of the water heater will be automatic. Thermostats on single element and dual element models are factory set to 125°F and 135°F, respectively. -
Page 15: Section Vi: Maintenance
SECTION VI: MAINTENANCE WATER PIPING On an annual basis, all piping should be checked for leakage at joints, shut-off valves, and unions. T&P RELIEF VALVE On an annual basis, the temperature and pressure relief valve should be checked for proper operation. -
Page 16: Section Vii: Troubleshooting
SECTION VII: TROUBLESHOOTING PROBLEM CAUSE SOLUTION No hot water at faucet High limit tripped Determine cause of High limit trip (faulty tempera- ture regulation at thermostat?). Replace combina- tion thermostat & high limit if necessary or reset high limit (depress red button). Improper thermostat setting Turn thermostat to safe temperature setting Electrical problem (relay, wiring, etc.) -
Page 17: Section Viii: Parts List
SECTION VIII: PARTS LIST Figure 6: Single Element Models Figure 6: Single Element Models Table 9: Parts List - Single Element Models Part Description Anode Rod Thermostat Mounting Bracket T&P Relief Valve Thermostat Cover Heating Element Foam Dam Cover Heating Element Gasket Access Cover Thermostat 10 Junction Box... - Page 18 SECTION VIII: PARTS LIST (cont .) Figure 7: Dual Element Models Table 10: Parts List - Dual Element Models Part Description Anode Rod Thermostat Cover Pipe Nipple 10 Foam Dam Cover Dip Tube 11 Junction Cabinet T&P Relief Valve 12 Terminal Block Heating Element 13 Drain Valve Heating Element Gasket...
-
Page 19: Section Ix: Warranty
If the tank is leaking and we have verified that the leak is due to a defect in materials and workmanship, we will replace the tank with a tank that is the nearest Bock model available at the time of replacement. If a replacement tank is provided, it will remain warranted under this section as if it were the original tank. - Page 20 INDIRECT, AND WHETHER ARISING IN CONTACT OR TORT. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you. Bock Water Heaters, Inc. • 110 South Dickinson Street • Madison, WI 53703 Telephone 608 -257-2225 • Fax 608 -257- 5304 www.bockwaterheaters.com...
