DLP Cinema ® Projector English NC1600C Deutsch Français Important Information 日本語 中文...
Page 3
DLP Cinema ® Projector English NC1600C Deutsch Français Important Information 日本語 中文 ...
Page 4
• The complete user’s manual is supplied on the CD-ROM in PDF (Portable Document Format) and provides detailed product and usage information for your NEC projector. The manual is available in five languages (English, German, French, Japanese and Chinese). To view or print the PDF files Adobe Acrobat Reader™ or Adobe Reader™ is required.
Page 5
DOC compliance Notice Please read this manual carefully before using your This Class A digital apparatus meets all requirements of the NC1600C and keep the manual handy for future reference. Canadian Interference-Causing Equipment Regulations. Important Safeguards Machine Noise Information Regulation - 3. GPSGV,...
Page 6
Important Information • Do not place the projector in the following conditions: • When main body is damaged, cooling fluids may come out - near water, baths or damp rooms. of internal part. DO NOT touch and drink the cooling fluid. - on an unstable cart, stand, or table.
Page 7
Contact your dealer or the following support branches for ques- tions relating to unclear points, malfunctions and repairs of the product. In Europe NEC Europe, Ltd. / European Technical Centre Address: Unit G, Stafford Park 12, Telford TF3 3BJ, U.K. Telephone: +44 1952 237000 Fax Line: +44 1952 237006...
1. What’s in the Box? Check the content of the accessories. NC1600C projector Exhaust outlet protective sheet fastening band x 4 Small iris x 1 Remote control (RD-371E) Lamp door key x 2 UM-3 AA size battery (for the remote control) x 2...
2. Troubleshooting Before asking for repair, please check your connection, settings and operation once again. If the trouble cannot be corrected, please contact your dealer/distributor for instructions or repair. Problems and where to check Problem Check these items The projector cannot be turned on. Check to see if the power plug is properly connected to the outlet.
3. Indicator display list See the descriptions below when the blinking or lighting of the two indicators on the projector’s control panel and the rear STATUS indicator on the backside of the projector is observed. The projector also has a warning function that uses a buzzer. MMS STATUS indicator ST ATUS POWER indicator...
Page 11
3. Indicator display list Rear STATUS indicator Indicator condition Projector condition Note Main power is off. Blinking light Green The projector is getting ready to turn on. Wait for a moment. The douser is closed. Orange The projector is cooling down. Wait for a moment.
4. Error code list Please inquire your dealer/distributor about action to be taken for each error code. Description is omitted for error codes 20 to 92. Error code Error message Desctiption Lamp Door Open Lamp door is open. Lamp OverTemp Temperature (lamp temperature) is abnoramal.
Page 13
4. Error code list Error code Error message Desctiption PB FPGA Reg R/W Fail PB Serial-ID Chip Fail PB CLUT-SRAM Fail PB OvFS-SDRAM Fail PB Resizer FIR Fail PB Resizer FIFO Fail PB Other Fail FB Red RDRAM Signature Fail FB Green RDRAM Signature Fail FB Blue RDRAM Signature Fail Bulb OverTime...
IEC60950-1 CISPR. 22 (Note) Using any lamp other than NEC’s optional lamps will result in lower brightness compared to NEC optional lamps. If brightness is important to you, it is recommended that you use NEC’s optional lamps. NEC will post information on its homepage regarding installable lamps, other than NEC’s optional lamps. Note that NEC does not guarantee performance and reliability when lamps other than NEC’s optional lamps are installed.
Page 15
DLP Cinema ® Projector English NC1600C Deutsch Français Wichtige Informationen 日本語 中文 ...
Page 17
Entsorgung Ihres benutzten Gerätes Lesen Sie sich dieses Handbuch bitte sorgfaltig durch, bevor Die EU-weite Gesetzgebung, wie sie in jedem Sie den NC1600C benutzen, und bewahren Sie das einzelnen Mitgliedstaat gilt, bestimmt, dass Bedienungshandbuch in greifbarer Nahe als spatere benutzte elektrische und elektronische Geräte Referenz auf.
Page 18
Wichtige Informationen • Schalten Sie den Projektor aus, ziehen Sie das Netzkabel • Schalten Sie die Stromversorgung des Projektors aus und ab und beauftragen Sie bitte Ihren qualifizierten trennen Sie sämtliche Kabel ab, bevor Sie den Projektor Servicetechniker unter den folgenden Bedingungen zu: an einen anderen Ort stellen.
Page 19
Lampe ab, bevor Sie den Projektor transportieren. Setzen In Europa Sie den Projektor keinen harten Stößen aus. NEC Europe, Ltd. / European Technical Centre • Geben Sie Acht, dass keine Fingerabdrücke oder Staub Addresse: Unit G, Stafford Park 12, Telford TF3 3BJ, U.K.
Page 20
1. Lieferumfang Überprüfen Sie den Inhalt des Zubehörs. NC1600C Projektor Befestigungsband für Auslass-Schutzfolie x 4 Kleine Iris x 1 Fernbedienung (RD-371E) Schlüssel für Lampentür x 2 UM-3 AA Batterie (für Fernbedienung) x 2 Bogen mit Beschriftungsaufklebern (für 20 Aufkleber) x 2...
2. Fehlersuche Überprüfen Sie den Anschluss, die Einstellungen und den Betrieb noch einmal, bevor Sie den Projektor reparieren lassen. Wenn die Störung nicht behoben werden kann, wenden Sie sich für Anweisungen oder Reparaturarbeiten an Ihren Händler/Lieferanten. Störungen und Überprüfung Störung Überprüfen Sie diese Punkte Der Projektor kann nicht Überprüfen Sie, ob der Netzstecker ordnungsgemäß...
Page 22
3. Anzeige-Displayliste Lesen Sie die unten stehenden Beschreibungen, wenn die zwei Anzeigen auf dem Bedienfeld des Projektors und die STATUS- Anzeige auf der Rückseite des Projektors blinken oder leuchten. Der Projektor verfügt ferner über eine Warnfunktion, die einen Summer einsetzt. MMS STATUS-Anzeige ST ATUS Netzanzeige (POWER)
Page 23
3. Anzeige-Displayliste Rückwärtige STATUS-Anzeige Anzeige-Zustand Projektor-Zustand Hinweis Die Hauptstromversorgung ist ausgeschaltet. Blinkendes Grün Der Projektor macht sich für die Einschaltung bereit. Warten Sie einen Moment. Licht Der Douser ist geschlossen. Warten Sie einen Moment. Orange Der Projektor kühlt sich ab. Warten Sie einen Moment. Rot (mit Summer) Sicherheitsproblem, Fehler Eine Fehlermeldung wird auf dem...
Page 24
4. Fehlercodeliste Bitte fragen Sie Ihren Händler/Lieferanten, welche Maßnahme zu dem jeweiligen Fehlercode ausgeführt werden muss. Die Beschreibung der Fehlercodes 20 bis 92 wurde weggelassen. Fehlercode Fehlermeldung Beschreibung Lamp Door Open Lampentür ist offen. Lamp OverTemp Temperatur (Lampentemperatur) ist nicht normal. GPSU Fail Stromversorgung ist nicht normal.
Page 25
4. Fehlercodeliste Fehlercode Fehlermeldung Beschreibung PB FPGA Reg R/W Fail PB Serial-ID Chip Fail PB CLUT-SRAM Fail PB OvFS-SDRAM Fail PB Resizer FIR Fail PB Resizer FIFO Fail PB Other Fail FB Red RDRAM Signature Fail FB Green RDRAM Signature Fail FB Blue RDRAM Signature Fail Bulb OverTime Lampenkolben-Gesamtbetriebszeit ist abgelaufen.
IEC60950-1 CISPR. 22 (Hinweis) Wenn Sie eine andere Lampe als die optionalen Lampen von NEC verwenden, wird im Vergleich zu den optionalen NEC-Lampen eine geringere Helligkeit erzielt. Wenn die Helligkeit für Sie ein wichtiger Faktor ist, ist es empfehlenswert, die optionalen Lampen von NEC zu verwenden.
Page 27
DLP Cinema ® Projector English NC1600C Deutsch Français Informations Importantes 日本語 中文 ...
Page 28
Le mode d’emploi complet est fourni avec le CD-ROM en format PDF (Portable Document Format) et donne des informations détaillées sur le produit et l’utilisation pour votre projecteur NEC. Le manuel est disponible en cinq langues (anglais, allemand, français, Japonais et Chinois).
Page 29
Informations Importantes Précaution: DOC avis de conformité Lire attentivement ce manuel avant dÅfutiliser le NC1600C Cet appareil numérique de la classe A respecte toutes les et le conserver à portée de main pour future référence. exigences du Réglement sur le Matériel D’interférence du Canada.
Page 30
Informations Importantes • Si une des conditions suivantes se présente, éteignez le à un autre endroit. projecteur, débranchez le câble d’alimentation et consulter Pour l’installation du cordon d’alimentation électrique sur votre technicien qualifié: le projecteur, voir le concessionnaire. NE PAS intaller le - Le câble ou la prise d’alimentation est endommagé...
Page 31
Prendre soin En Europe en manipulant l’écran. NEC Europe, Ltd. / European Technical Centre • Le transport du projecteur doit être effectué par six Adresse : Unit G, Stafford Park 12, Telford TF3 3BJ, U.K.
1. Que contient la boîte ? Vérifiez le contenu de la boîte. Projecteur NC1600C 4 liens de fixation de la feuille de protection de la sortie dユair 1 petit diaphragme Téléommande (RD-371E) 2 clés pour le logement de la lampe 2 piles de type UM-3 AA (pour la téléommande)
2. Dépistage des pannes Avant de demander une réparation, veuillez vérifier de nouveau votre connexion, les réglages et le fonctionnement. Si vous ne réussissez pas à corriger le problème, veuillez contacter votre revendeur/distributeur pour obtenir des instructions ou pour qu’il vienne réaliser la réparation. Problèmes et éléments à...
3. Liste d’affichage des voyants Référez-vous aux descriptions ci-dessous lorsque vous observez le clignotement ou l’allumage fixe des deux voyants situés sur le panneau de commande du projecteur et du voyant STATUS arrière situé sur l’arrière du projecteur. Le projecteur possède également une fonction d’avertissement qui utilise un avertisseur sonore.
Page 35
3. Liste d’affichage des voyants Voyant STATUS arrière Etat du voyant Indicator condition Projector condition Note Main power is off. Blinking light Green The projector is getting ready to turn on. Wait for a moment. The douser is closed. Orange The projector is cooling down.
4. Liste des codes d’erreur Veuillez consulter votre revendeur/distributeur pour savoir quelle mesure prendre pour chaque code d’erreur. La description est omise pour les codes d’erreur 20 à 92. Error code Error message Desctiption Lamp Door Open Lamp door is open. Lamp OverTemp Temperature (lamp temperature) is abnoramal.
Page 37
4. Liste des codes d’erreur Code d'erreur Message d'erreur Description PB FPGA Reg R/W Fail PB Serial-ID Chip Fail PB CLUT-SRAM Fail PB OvFS-SDRAM Fail PB Resizer FIR Fail PB Resizer FIFO Fail PB Other Fail FB Red RDRAM Signature Fail FB Green RDRAM Signature Fail FB Blue RDRAM Signature Fail Bulb OverTime...
NEC affichera sur sa page Internet les informations concernant les lampes, autres que les lampes optionnelles NEC, pouvant être installées. Veuillez noter que NEC ne garantit pas le bon fonctionnement et la fiabilité lorsque des lampes autres que les lampes optionnelles NEC sont installées.
Page 39
DLP Cinema ® Projector English NC1600C Deutsch Français Important Information 日本語 中文...
Page 64
包装箱内有哪些物件 确认包装箱内下列各项物件是否齐全。 排气口保护纸扎带 x 4 NC 1600C 投影机 小虹膜 x 1 灯箱钥匙 x 2 遥控器 (RD-371E) UM-3 AA 尺寸电池 (用于遥控器) x 2 标题标签片 (用于 20 张标签) x 2 遥控缆线 (16 m) x 1 重要信息 x 1 灯泡附件 x 1 CD-ROM (用户手册) 排气口保护片...
