Quick
Installation Guide
MW155R
150Mbps Wireless N Router
1
Connect the
Hardware
Note: If your Internet connection is through an Ethernet cable from the
wall instead of through a DSL/Cable/Satellite modem, connect the
Ethernet cable directly to the router's WAN port.
Modem
2
Conf igure the
Router
1
Connect your computer to the router (Wired or Wireless).
Wired
RESET
POWER
WAN
LAN
WAN
LAN
POWER
RESET
Internet
2. Connect an Ethernet cable from the
modem to the WAN port on your router.
1. Turn o the modem, and remove
the backup battery if it has one.
3. Power on the modem, wait about 2
minutes for it to restart.
Power Adapter
4. Power on the router.
Wireless
Connect wirelessly using the SSID (Network Name) printed on the product label at
the bottom of the router.
For more information, please visit our website:
Router
WPS/
RESET
POWER
WAN
LAN
5. Verify that the hardware connection is
correct by checking the following LEDs.
WAN
Power
On
On/Flashing
http://www.mercusys.com
7107500055 REV1.0.0
Advertisement
Related Manuals for Mercu MW155R
Summary of Contents for Mercu MW155R
- Page 1 Quick Installation Guide For more information, please visit our website: MW155R http://www.mercusys.com 150Mbps Wireless N Router 7107500055 REV1.0.0 Connect the Hardware Note: If your Internet connection is through an Ethernet cable from the wall instead of through a DSL/Cable/Satellite modem, connect the Ethernet cable directly to the router’s WAN port.
-
Page 2: Led Indicators
Con gure the router using a web browser. Enter http://mwlogin.net in the address bar of the web browser. Create a login Click Next to start Quick Setup. Choose your connection type. If you are unsure of your password when prompted, then click OK. connection type, choose Auto-Detect.
