Ideal Security Decibel SL1000 Instructions

SL1000 Decibel Multi-Use Cable
Lock with Alarm Instructions
The SL1000 Decibel Cable Lock with Alarm provides the ultimate theft deterrent
by integrating a 120 decibel siren with a robust cable lock.
Features:
Secure nearly anything, large or small, with a strong steel cable (ex.
•
bicycles, grills, ladders, lawnmowers, tools).
120 decibel siren scares away potential thieves if the steel cable has been
•
cut approximately 50%.
Comes with 2 keys. Register yours at www.decibellocks.com
•
replacements.
Two additional brackets are included to create a fixed locking point by
•
attaching your Decibel Cable Lock with Alarm to the floor, wall, or side of
a building, or to secure the alarm to the item you're protecting. For more
information, please see below.
Included with this Product:
1. Decibel Cable Lock
2. Surface mount bracket
3. U-bracket
4. 2x #8 2¾" screws
5. 2x #8 1¼" screws
6. 4x plastic plugs
7. 2x keys
Requires 9 volt battery (not included).
Parts of the Lock
1. Lock body
2. Lock cylinder
3. Cable
4. Cable clamp
5. Cable lock hole
Opening the Cover
1. Open the cable clamp (Fig. 3).
2. Unwrap the cable entirely. This will reveal
the cover release tabs on the top and
bottom of the cable lock (Fig. 4).
3. Ensure the key lock is turned to the
unlocked (vertical) position.
4. Press a screwdriver into the release tab on the top or bottom of the lock,
then tilt the tip of the screwdriver upwards to pop the cover off (Fig. 5).
Remove the cover.
to order
Fig. 4
Installing the Battery
1. Open the cover.
2. Using a Phillips screwdriver, remove
the screw on the battery cover.
Remove the battery cover (Fig. 6).
3. Attach a high-quality 9-volt alkaline
battery to the battery terminal (not included).
4. Insert the red and black wires of the battery terminal into one of the
grooves in the metal bracket (Fig. 7). Insert the battery. This will ensure
the wires do not get pinched.
Fig. 1
5. Replace the battery cover. Tighten the
screw.
6. Close the cover.
7. Without inserting the cable into the cable
lock hole, test the alarm by turning the
key in the lock cylinder to the locked position. The alarm should sound
within a few seconds. If it does not, replace the battery.
Note: Check the battery regularly to ensure the best pos sible lock
performance. Regularly test the alarm, and check the strength of
the LED light; when the battery is running lo w, the LED light will
Fig. 2
become faint. It will stop flashing once the battery is almost empty.
Batteries should last approximately 6-12 months.
Closing the Cover
1. The tab on the left-hand side of
Fig. 3
the cover fits onto the outside of
the lock, and the tabs on the top
and bottom fit inside. Insert the
left and bottom tabs first (Fig. 8).
Press the top tab inwards, being careful of your fingers, and push the
cover down into place. Both the release tabs should snap into place and
must be sticking out from the holes.
Using the Decibel Cable Lock
Fig. 5
1. Open the cable clamp and unwrap the cable.
2. Wrap the cable around or through items you wish to secure. If the lock is
freestanding or attached to the item being protected, pass the cable
through a fixed object such as a post or railing. If locking a bicycle, wrap
the cable through the frame, both wheels, and the fixed object for optimal
security.
3. Leave as little slack on the cable as possible by wrapping any excess cable
around or through objects multiple times.
4. Open the black tab next to the lock cylinder, revealing the cable lock hole.
Fig. 6
Tip: Thieves have better leverage to attack locks that are located
near the ground. Secure the lock and cable a fe w feet above the
ground to best deter thieves.
5. Insert the steel end of the cable firmly into the cable lock hole. Ensure it
is inserted fully. On recently-purchased locks, the cable may require
additional, gentle force to fit into the cable lock hole. See Troubleshooting
for more information.
Fig. 7
6. Insert the key into the lock cylinder and turn it ¼ turn to the right.
Remove the key. The LED light will flash a few times to indicate that it is
now locked and armed. It will then flash every 4-5 seconds.
7. To unlock your Decibel Cable Lock, insert the key and turn it a ¼ turn to
the left. Remove the cable from the cable lock hole. For easy storage,
wrap the cable around the lock and close the cable clamp.
Fig. 8
