Summary of Contents for Chauvet DJ D-Fi Series

  • Page 1 User Manual...

  • Page 2: Table Of Contents

    ABLE OF ONTENTS 1. Before you Begin ........................ 3 What Is Included ............................ 3 Unpacking Instructions .......................... 3 Claims ................................3 Text Conventions ........................... 3 Symbols ..............................3 Disclaimer .............................. 3 Safety Notes ............................4 FCC Compliance ........................... 4 2. Introduction ......................... 5 Product Overview ..........................

  • Page 3: Before You Begin

    1. B EFORE YOU EGIN · · D-Fi™ Hub Quick Reference Guide What Is · Power Supply Included Unpacking Carefully unpack the product immediately and check the container to make sure all the parts are in the package and are in good condition. Instructions Claims If the box or the contents (the product and included accessories) appear damaged from...

  • Page 4: Safety Notes

    Safety Notes Please read the following Safety Notes carefully before working with this product. They include important safety information about its installation, usage, and maintenance. · Always connect this product to a grounded circuit to avoid the risk of electrocution. ·...

  • Page 5: Introduction

    2. I NTRODUCTION Product Overview Antenna Right View Antenna Storage Left View Display and Control Buttons DC Power In DMX In DMX Out D-Fi™ Hub User Manual Rev. 2 Page 5 of 12...

  • Page 6: Product Dimensions

    Product Dimensions 5.59 in 142 mm (Mounting Holes) 3.58 in 91 mm 2.36 in 60 mm 1.81 in 46 mm 3.3 in 84 mm Page 6 of 12 D-Fi™ Hub User Manual Rev. 3...

  • Page 7: Setup

    3. S ETUP This product has an auto-ranging external power supply and it can work with an input AC Power voltage of 100 to 240 VAC, 50/60 Hz. It runs on 9 VDC, 500 mA. To determine the power requirements for this product (power outlet and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart.

  • Page 8: Operation

    4. O PERATION To access the control panel functions, use the four buttons located around the display. Control Panel Please refer to the Product Overview to see the buttons location on the control panel. Operation Button Function Press to find an operation mode or to back out of the current menu <MENU>...

  • Page 9: Programming And Signal Selection

    Programming To connect the D-Fi™ Hub to a DMX controller and configure it to transmit to D-Fi™-compatible lights, do the following: and Signal Connect the hub to the controller using a DMX cable. Selection Connect the hub to power. If the display shows Transmit Manual <CHXX>, where XX is a value between 01 and 16, the hub is already configured for manual transmission.

  • Page 10: Technical Information

    5. T ECHNICAL NFORMATION Technical Specifications Dimensions and Length Width Height Weight Weight 5.59 in (142 mm) 3.58 in (91 mm) 1.81 in (46 mm) 1.2 lb (0.6 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Power Supply Type Range Input Voltage...

  • Page 11: Returns

    To return a product or request support: · If you live in the U.S., contact Chauvet World Headquarters (see Contact Us). · If you live in the U.K. or Ireland, contact Chauvet Europe Ltd. (see Contact Us). · If you live in Mexico, contact Chauvet Mexico (see Contact Us).

  • Page 12: Contact Us

    General Information Technical Support Contact Chauvet World Headquarters Address: 5200 NW 108th Avenue Voice: (844) 393-7575 Sunrise, FL 33351 Email: Voice: (954) 577-4455 chauvetcs@chauvetlighting.com Toll free: (800) 762-1084 Website: www.chauvetprofessional.com Chauvet Europe Ltd Address: Unit 1C Email: Brookhill Road Industrial uktech@chauvetlighting.com Estate Pinxton, Nottingham, UK...
