- Page 1 YAMAHA ® ® REAR SPEAKER WIRE KIT RFYXZ-RSW16 Serial Number: Date of Purchase: Installation & Operation...
- Page 2 12 Warranty ©2016 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE and associated logos where applicable are registered trademarks of Rockford Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Specifications subject to change without notice.
- Page 3 This section focuses on some considerations for installing your Yamaha YXZ rear speaker kit. This manual will illustrate the installation process with a 2017 Yamaha YXZ1000R SS with a RFYXZ-RSW16 wiring kit. If you feel unsure about installing this system yourself, have it installed by a qualified technician.
- Page 4 Installation Applicable Models: 2016 & Up YXZ1000R/YXZ1000R SS This rear speaker wire kit is designed to work with Rockford Fosgate’s RFYXZ-K8 and RFYXZ-PMXDK audio kits. The wire harnesses plug directly into PM2652W-MB and RM1652W-MB wake tower speaker enclosures. NOTE: Some additional interior pieces were removed to make photography easier for documenting the installation process.
- Page 5 Installation Step 4 - Remove Passenger Side Panel After the center console is out of the way, remove these (5) plastic rivets with a flat blade screwdriver. Once the plastic rivets are removed, lift up on the shifter surround plastic to expose (2) more rivets needed for the removal of the plastic side panel.
- Page 6 NOTE: Be sure to leave enough slack so you can connect the speaker to the connector. PM-CL2B Bracket (not included in kit) RFYXZ-RSW16 Wire Harness Mounting Tab Wake Can Speaker Enclosure Step 6 - Attach Wake Can Speaker Enclosure to Bracket...
- Page 7 Installation Step 7 - Mounting Wake Can Enclosure to Roll Cage Continue to route the harness down the rear tube through the panel opening. Position the speaker/clamp assembly with the speaker to the inside of the roll cage and approximately 4-5 inches behind the rear down tube. NOTE: There is enough supplied wire length to mount the speaker cans anywhere on the rear down bars.
- Page 8 Installation Be sure that enough of the center console is removed to gain access to the With both left and right speaker harnesses now pulled through, continue to wire harness. run down the center console them toward the front of the vehicle. Feed the harness between the panels making sure to pull all available slack Run the harnesses along the main vehicle wire bundle and secure with through to the center console area.
- Page 9 Installation Feed the harnesses up through the transmission tunnel into the hood compartment area. Once there, the harnesses are now ready for connection to the RFYXZ-DK radio harness or the RFYXZ-K8 amplifier installation kit harness. Refer to the appropriate installation manual for more information on making these connections.
- Page 12 What is Covered This warranty applies only to Rockford Fosgate products sold to consumers by authorized Rockford Fosgate dealers in the United States of America. Prod- ucts purchased by consumers from an Authorized Rockford Fosgate Dealer in another country are covered only by that country’s Distributor and not by Rockford Corporation.
- Page 13 Installation assistance available at: www.rockfordfosgate.com/rftech 600 South Rockford Drive • Tempe, Arizona 85281 United States Direct: (480) 967-3565 • Toll Free: (800) 669-9899 R O C K F O R D F O S G A T E . C O M...
