INSTALLATION & OPERATION MANUAL
Gas Countertop Hot Plate
MODELS: KF-HP12-M,
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION,SERVICE OR
MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE
INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.
Please call the Service Department and ask for contact information for your local service company.
KF-HP24-M
(12"-2 burners) (24"-4 burners)
For Service on Your Gas Hot Plate:
1
KF-HP36-M
&
(36"-6 burners)
Advertisement
Related Manuals for KFE KF-HP12-M
Summary of Contents for KFE KF-HP12-M
- Page 1 INSTALLATION & OPERATION MANUAL Gas Countertop Hot Plate MODELS: KF-HP12-M, KF-HP24-M KF-HP36-M & (12”-2 burners) (24”-4 burners) (36”-6 burners) WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION,SERVICE OR MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.
- Page 2 This manual contains important safety instructions which must be strictly followed when using this equipment. Please retain this manual for future reference. Index ATTENTION OWNERS AND OPERATORS..................3 INSTALLATION…………………………………………………………………….……….4-5 UNPACKING & WARNINGS & SAFEGUARDS FOR OPERATION ................6 OPERATINGINSTRUCTIONS………………………………………………………………….……….……7 CLEANING INSTRUCTIONS …………………………………………………………………………….…..8 TROUBLESHOOTING .........................9 LIMITED WARRANTY………………………………………………………………………………………..10...
-
Page 3: Attention Owners And Operators
Attention Owners and Operators The equipment is designed to provide safe and productive processing, cooking and warming of food products as long as the equipment is used in accordance with the instructions in this manual and is properly maintained. Unless the operator is adequately trained and supervised there is a possibility of serious injury. Owners of this equipment bear the responsibility to make certain that this equipment is used properly and safely, and to strictly follow all of the instructions contained in this manual and the requirements of local, state or federal law. - Page 4 If the machine is found to be damaged, save the packaging material and contact the carrier within fifteen (15) days of delivery. Immediately contact KFE or your local dealer of the equipment. You have no recourse for damage after fifteen (15) days.
- Page 5 Unpacking & Installation INSTALLATION 1. Read this manual thoroughly before installation and operation. DO NOT proceed with installation and operation if you have any questions or do not understand anything in this manual. Contact your local representative. 2. Select a location for the hot plate that has a level, solid, nonskid surface that is nonflammable and away from water hazards or sinks, and is in a well-lighted work area away from children and visitors.
- Page 6 TO AVOID SERIOUS PERSONAL INJURY AND PROPERTY DAMAGE: For your safety, do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliances. Keep the area free and clear of combustible. ( See ANSI Z83. 14B, 1991). Improper installation, adjustment, alteration, service or maintenance of this equipment can cause property damage, personal injury, or death and voids warranty.
-
Page 7: Operating Instructions
Operating Instructions Operating the Hot Plate - Pilot Lighting Instructions Before operating hot plate, it should be checked to see that it is sitting level. Adjust the feet to level the hot plate. Be sure the catch tray has been properly placed. The pilot lights on the appliance have been set at the factory. - Page 8 · DO NOT use any abrasive or flammable cleaning fluids. · DO NOT hose down, immerse or pressure wash any part of the hot plate, excluding the catch tray. · NEVER use a scrubber pad, steel wool or abrasive material, or cleaners containing chlorine, iodine and ammonia or bromine chemicals as these will deteriorate the stainless steel and shorten the life of the unit.
-
Page 9: Troubleshooting
Troubleshooting ISSUE CAUSE SOLUTION Hot plate not lighting Main gas line is closed Open valve Pilot light is not lit Ignite pilot light Cause unknown Call for service Flame is too high or too low Adjust flame with control knob Adjustment knob is turned up or down Pilot light not staying lit... - Page 11 Conversion Kit Instructions for Gas Countertop Hot Plate Models: 12”-2 burners 24”-4 burners 36”-6 burners These conversion instructions are for conversion of the HOT PLATE. The instructions provide in this kit are for the conversion of Natural Gas to L.P. gas and refer to the conversion of the unit and kit provided. An authorized licensed technician must be called to perform the complete conversion of the unit.
- Page 12 Pictured is the plastic insert. Pull off insert from octagon cap and reverse the plastic insert position so that the L.P. position is attached to Before installing the included convertible the octagon cap head. regulator, unscrew the octagon cap. You can read (NAT) on the plastic insert attached to the head of the cap;...
