Table Trough Installation Sheet
FIGURE 1
Oasis Mini UT
8.25
14.12
MINI UT
TM
Mounting Screws
Not provided
Thumb Nut & Washer
2 Per Insert
Cutout
Length
Removable
Inserts
TM
OASIS
Pan
FIGURE 2
Advertisement
Table of Contents
Related Manuals for Dekko ECA OASIS UT
Summary of Contents for Dekko ECA OASIS UT
- Page 1 OASIS UT & OASIS MINI UT Table Trough Installation Sheet FIGURE 1 Cutout Length Cutout Width Mounting Screws Not provided FIGURE 2 Thumb Nut & Washer CUTOUT SIZES 2 Per Insert Oasis UT Oasis Mini UT Cutout 8.25 8.25 Width Cutout 29.12 14.12...
-
Page 2: Installation Instructions
Installation Instructions 1. Cutout table as required (see Figure 1 & Cutout Sizes) 2. Center OASIS UT on cutout from below and mount with screws as shown, not provided. 3. OASIS Inserts may have been installed at the factory but may be repositioned in the field if desired.
