ASROCK H310CM-HDVP2 Manual
  1. Manuals
  2. Brands
  3. ASROCK Manuals
  4. Motherboard
  5. H310CM-HDVP2
  6. Manual
ASROCK H310CM-HDVP2 Manual

ASROCK H310CM-HDVP2 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Version 1.0
Published July 2018
Copyright©2018 ASRock INC. All rights reserved.

Copyright Notice:

No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identification or explanation and to the owners' benefit, without intent to
infringe.
Disclaimer:
Specifications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or fitness for a particular
purpose.
In no event shall ASRock, its directors, officers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of profits, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
"Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate"
ASRock Website: http://www.asrock.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H310CM-HDVP2 and is the answer not in the manual?

Questions and answers

Related Manuals for ASROCK H310CM-HDVP2

Summary of Contents for ASROCK H310CM-HDVP2

  • Page 1: Copyright Notice

    (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 2 You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply) The terms HDMI™...

  • Page 3: Motherboard Layout

    H310CM-HDVP2 Motherboard Layout RoHS CPU_FAN1 ATX12V1 USB 2.0 T: USB0 B: USB1 USB 3.1 Gen1 Top: T: USB0 RJ-45 B: USB1 HD_AUDIO1 CHA_FAN1/WP H310CM-HDVP2 PCIE1 CMOS PCIE2 Battery Intel H310 PCIE3 BIOS PCI1 PANEL1 PLED PWRBTN COM2 CHA_FAN2 LPT1 USB_4_5...
  • Page 4 No. Description ATX 12V Power Connector (ATX12V1) CPU Fan Connector (CPU_FAN1) 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1) ATX Power Connector (ATXPWR1) USB 3.1 Gen1 Header (USB3_2_3) USB 2.0 Header (USB_8_9) (shared with USB3_2_3) SATA3 Connector (SATA3_3) SATA3 Connector (SATA3_2) SATA3 Connector (SATA3_1) SATA3 Connector (SATA3_0) Clear CMOS Jumper (CLRMOS1)
  • Page 5 H310CM-HDVP2 I/O Panel No. Description No. Description PS/2 Mouse Port Microphone (Pink)** COM Port USB 3.1 Gen1 Ports (USB01) D-Sub Port USB 2.0 Ports (USB01) LAN RJ-45 Port* HDMI Port Line In (Light Blue)** DVI-D Port Front Speaker (Lime)** PS/2 Keyboard Port * There are two LEDs on each LAN port.
  • Page 6 ** To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi- channel audio feature through the audio driver. Please set Speaker Configuration to “7.1 Speaker”in the Realtek HD Audio Manager. Function of the Audio Ports in 7.1-channel Configuration: Port Function...

  • Page 7: Chapter 1 Introduction

    If you require technical support related to this mother- board, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 8: Specifications

    1.2 Specifications Platform • Micro ATX Form Factor • Solid Capacitor design • Supports 8 Generation Intel® Core Processors (Socket 1151) • 4 Power Phase design • Supports Intel® Turbo Boost 2.0 Technology Chipset • Intel® H310 Memory • Dual Channel DDR4 Memory Technology • 2 x DDR4 DIMM Slots • Supports DDR4 2666/2400/2133 non-ECC, un-buffered memory...
  • Page 9 H310CM-HDVP2 • Three graphics output options: D-Sub, DVI-D and HDMI * Supports up to 2 displays simultaneously • Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 30Hz • Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz • Supports D-Sub with max.
  • Page 10 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen2 x2 (10 Gb/s)** ** Supports NVMe SSD as boot disks ** Supports ASRock U.2 Kit Connector • 1 x Print Port Header • 1 x COM Port Header • 1 x TPM Header...
  • Page 11 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 12: Chapter 2 Installation

    Chapter 2 Installation This is a Micro ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 13: Installing The Cpu

    H310CM-HDVP2 2.1 Installing the CPU 1. Before you insert the 1151-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 14 Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.
  • Page 15 H310CM-HDVP2 2.2 Installing the CPU Fan and Heatsink...

  • Page 16: Installing Memory Modules (Dimm)

    2.3 Installing Memory Modules (DIMM) This motherboard provides two 288-pin DDR4 (Double Data Rate 4) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR4 DIMM pairs. 2.

  • Page 17: Expansion Slots (Pci And Pci Express Slots)

    H310CM-HDVP2 2.4 Expansion Slots (PCI and PCI Express Slots) There are 1 PCI slot and 3 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 18: Jumpers Setup

    2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper Short: Clear CMOS (CLRCMOS1) Open: Default 2-pin Jumper...

  • Page 19: Onboard Headers And Connectors

    H310CM-HDVP2 2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header...
  • Page 20 Chassis Intrusion and Please connect the SPEAKER DUMMY Speaker Header chassis power LED and DUMMY (7-pin SPK_CI1) the chassis speaker to this (see p.1, No. 15) header. SIGNAL DUMMY Serial ATA3 Connectors These four SATA3 (SATA3_0: connectors support SATA see p.1, No. 9) data cables for internal (SATA3_1: storage devices with up to...
  • Page 21 H310CM-HDVP2 Front Panel Audio Header This header is for OUT_RET OUT2_L (9-pin HD_AUDIO1) J_SENSE connecting audio devices MIC_RED OUT2_R (see p.1, No. 20) to the front audio panel. PRESENCE# MIC2_R MIC2_L 1. High Definition Audio supports Jack Sensing, but the panel wire on the chassis must support HDA to function correctly.
  • Page 22 ATX Power Connector This motherboard (24-pin ATXPWR1) provides a 24-pin ATX (see p.1, No. 4) power connector. To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13. ATX 12V Power This motherboard Connector provides an 8-pin ATX (8-pin ATX12V1) 12V power connector.
  • Page 23 H310CM-HDVP2 2.7 M.2_SSD (NGFF) Module Installation Guide The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket (M2_1) supports SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen2 x2 (10 Gb/s).
  • Page 24 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw NUT2 NUT1 as this might damage the module. For the latest updates of M.2_SSD (NFGG) module support list, please visit our website for details: http://www.asrock.com...
  • Page 25 H310CM-HDVP2 1 개요 ASRock H310CM-HDVP2 마더보드를 구입해 주셔서 감사합니다 . 이 마더보드 는 ASRock 의 일관되고 엄격한 품질관리 하에 생산되어 신뢰성이 우수하며 , 품 질과 내구성에 대한 ASRock 의 기준에 부합하는 우수한 성능과 견고한 설계를 제공합니다 . 마더보드 규격과 BIOS 소프트웨어를 업데이트할 수도 있기 때문에 , 이 문서의 내...
  • Page 26 1.2 규격 • Micro ATX 폼 팩터 플랫폼 • 솔리드 콘덴서 구조 • 8 세대 Intel® Core 프로세서 지원 ( 소켓 1151) • 4 개 전원 위상 구조 • Intel® Turbo Boost 2.0 기술 지원 • Intel® H310 칩세트 • 듀얼 채널 DDR4 메모리 기술 메모리...
  • Page 27 H310CM-HDVP2 • HDMI 지원 ( 최대 해상도 4K x 2K (4096x2160) @ 30Hz) • DVI-D 지원 ( 최대 해상도 1920x1200 @ 60Hz) • D-Sub 지원 ( 최대 해상도 1920x1200 @ 60Hz) • Auto Lip Sync, Deep Color (12bpc), xvYCC 및 HBR (High Bit Rate Audio)(HDMI 포트...
  • Page 28 SATA3 6.0 Gb/s 모듈 및 Gen2 M.2 PCI Express 모듈을 2 개 (10 Gb/s) 까지 지원 ** ** NVMe SSD 를 부팅 디스크로 사용 가능하도록 지원 ** ASRock U.2 키트 지원 • 인쇄 포트 헤더 1 개 커넥터 • COM 포트 헤더 1 개...
  • Page 29 H310CM-HDVP2 1.3 점퍼 설정 그림은 점퍼를 어떻게 설정하는지 보여줍니다 . 점퍼 캡을 핀에 씌우면 점퍼가 “단락” 됩니다 . 점퍼 캡을 핀에 씌우지 않으면 점퍼가 “단선”됩니다 . 그림은 3 핀 점퍼를 보여주며 핀 1 과 핀 2 는 점퍼 캡을 씌울 때 “단락”됩니다 .
  • Page 30 1.4 온보드 헤더 및 커넥터 온보드 헤더와 커넥터는 점퍼가 아닙니다 . 점퍼 캡을 온보드 헤더와 커넥터에 씌 우지 마십시오 . 점퍼 캡을 온보드 헤더와 커넥터에 씌우면 마더보드가 영구적으로 손상됩니다 . PLED+ 섀시의 전원 스위치 , 시스템 패널 헤더 PLED- PWRBTN# (9 핀...
  • Page 31 H310CM-HDVP2 SPEAKER 섀시 침입 및 스피커 헤더 섀시 침입 및 섀시 스 DUMMY (7 핀 SPK_CI1) 피커를 이 헤더에 연결 DUMMY (1 페이지 , 15 번 항목 참조 ) 하십시오 . SIGNAL DUMMY 시리얼 ATA3 커넥터 이들 네 개의 SATA3 커...
  • Page 32 전면 패널 오디오 헤더 이 헤더는 오디오 장치 OUT_RET OUT2_L J_SENSE (9 핀 HD_AUDIO1) 를 전면 오디오 패널에 MIC_RED OUT2_R PRESENCE# MIC2_R (1 페이지 , 20 번 항목 참조 ) 연결하는 데 사용됩니 MIC2_L 다 . 1. 고음질 오디오는 잭 감지를 지원하지만 올바르게 작동하려면 섀시의 패널 와이 어가...
  • Page 33 H310CM-HDVP2 ATX 전원 커넥터 이 마더보드에는 24 핀 (24 핀 ATXPWR1) ATX 전원 커넥터가 탑 (1 페이지 , 4 번 항목 참조 ) 재되어 있습니다 . 20 핀 ATX 전원공급장치 를 사 용하려면 핀 1 과 핀 13 을 따라 연결하십...

  • Page 34: Contact Information

    Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp...

  • Page 35: Declaration Of Conformity

    DECLARATION OF CONFORMITY Per FCC Part 2 Section 2.1077(a) Responsible Party Name: ASRock Incorporation Address: 13848 Magnolia Ave, Chino, CA91710 Phone/Fax No: +1-909-590-8308/+1-909-590-1026 hereby declares that the product Product Name : Motherboard H310M-HDVP2 Model Number : Conforms to the following speci cations:...

  • Page 36: Eu Declaration Of Conformity

    EU Declaration of Conformity For the following equipment: Motherboard (Product Name) H310CM-HDVP2 / ASRock (Model Designation / Trade Name) ASRock Incorporation (Manufacturer Name) 2F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District, Taipei City 112, Taiwan (R.O.C.) (Manufacturer Address) EMC —Directive 2014/30/EU (from April 20th, 2016)
