BrakeBuddy Select II Instructions Manual

Portable braking system
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
39523
Select II
™
Portable Braking System
Inventor and Leader in Portable Technology!
INSTRUCTIONS
NEED HELP? CALL - 1-800-470-2287
(MONDAY - FRIDAY 8AM - 5PM CST)
WARNING
Read all instructions before installing or operating the Select II™.
Failure to understand how to install or operate Select II™ could result in property damage, personal injury or death.
Hopkins Manufacturing Corporation | 428 Peyton St. Emporia, KS 66801
| www.BrakeBuddy.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Select II and is the answer not in the manual?

Questions and answers

Summary of Contents for BrakeBuddy Select II

  • Page 1 WARNING Read all instructions before installing or operating the Select II™. Failure to understand how to install or operate Select II™ could result in property damage, personal injury or death. Hopkins Manufacturing Corporation | 428 Peyton St. Emporia, KS 66801...
  • Page 2 INSIDE THE BOX PRIOR TO THE SET-UP OF BRAKEBUDDY® SELECT II™, REMOVE ALL CONTENTS FROM THE SHIPPING PACKAGE. Select II™ Unit Handle Control Wireless Remote Dash Mount Connector Easy-Pull™ Power Cord Panel Handle Lock Release Break-Away Kit 15 AMP Charger Quick Connect™...
  • Page 3 Use 2 ¼” screws, 2 washers and 2 nuts to secure Dash Mount Connector to vehicle dash. BREAK-AWAY INSTALLATION THE BREAK-AWAY IS AN IMPORTANT PART OF THE BRAKEBUDDY® SYSTEM AND IS REQUIRED BY LAW IN MOST STATES. DO NOT OPERATE YOUR BRAKEBUDDY® WITHOUT A PROPERLY FUNCTIONING BREAK-AWAY.
  • Page 4 When the use of the towed vehicle is needed, simply unhook the small clip from the loop on the pull pin of the junction box. Unplug the power cord from the BrakeBuddy® and the dash mount. Store power cord with BrakeBuddy®.

  • Page 5: Diagnostic Features

    Adjust the Sensitivity either on the remote or on top of the main unit. The sensitivity is how hard you must apply the brakes in the motorhome before the BrakeBuddy® will engage the in your towed vehicle. The more lights that are illuminated, the easier the BrakeBuddy® will activate. Each time BrakeBuddy is installed, the sensitivity setting remains in the last used setting.
  • Page 6 FIG. 4 Power up / turn on both devices (dinghy and remote). On the BrakeBuddy® unit, hold down the (+) and ( _ ) buttons (A) simultaneously until the Air Pressure setting reads “LL” (Fig. 4 / E). Next, with the remote, hold down the Braking Mode (C) and Braking Sensitivity (D) buttons simultaneously for 5 seconds.

  • Page 7: Removal Instructions

    REMOVAL INSTRUCTIONS 1. To remove the BrakeBuddy® from your towed vehicle, unplug Easy-Pull™ Power Cord from unit and Dash Mount Connector 2. Adjust the seat back and remove the clevis 3. Disconnect (unclip) the break-away safety coil from the break-away junction box...

  • Page 8: What Is Not Covered

    WHAT IS NOT COVERED? Our warranty for your product will not cover damage resulting from neglect or misuse of the product, use of improper voltage or current, use contrary to operating instructions, or disassembly, repair, or alteration by any person other than an authorized service station. Any implied warranty of merchantability or fitness for a particular purpose of your product is limited to the duration of this written warranty.
